Yealink SIP-T46S Administrator's Guide

Administrator’s Guide for SIP-T2 Series/T4 Series/T5 Series/CP920 IP Phones
479
Variable Value Phone Action
A and D are in a call, the call is active;
B and D are in a call, the call is placed on hold;
C and D are in a call, the call is placed on hold;
callid_A: 32775
callid_B: 32776
Example:
http://10.10.20.10/servlet?key=ATrans=32775@32776
It means A and B join together and then disconnect with D. But the
call between C and D is still in a hold state.
Note: To get the call-id of the active call, configure the action URL:
http(s)://<serverIPAddress>/help.xml?CallId=$call_id. For more
information, refer to Action URL.
BTrans=xxx Perform a blind transfer to xxx.
phonecfg=get[&accounts=x][&dnd=x][&fw=x]
Get firmware version, registration, DND or forward configuration
information.
The valid value of “x” is 0 or 1, 0 means you do not need to get con-
figuration information. 1 means you want to get configuration inform-
ation.
Note: The valid URI is: http(s)://<phoneIPAddress > /ser-
vlet?phonecfg=get[&accounts=x][&dnd=x][&fw=x].
Example:
http://10.3.20.10/servlet?phonecfg=get[&accounts=1][&dnd=0]
[&fw=1]
phonecfg=set[&configuration para-
meter=value]
Set the valid value for the specified configuration parameter.
Note: The valid URI is: http(s)://<-
phoneIPAddress>/servlet?phonecfg=set[&configuration para-
meter=value]...[&configuration parameter=value]. It can contain up to
10 configuration parameters.
Example:
http://10.3.20.10/servlet?phone cfg=set[&account.1.enable=1][&fea-
tures.dnd.enable=1]
phonecfg=get[&configuration parameter]
Get the specified configuration information.
Note: The valid URI is: http(s)://<-
phoneIPAddress>/servlet?phonecfg=get[&configuration parameter]...
[&configuration parameter]. It can contain up to 10 configuration para-
meters.
Example:
http://10.3.20.10/servlet?phonecfg= get[&account.1.enable][&fea-
tures.dnd.enable]
CallWaitingOn Activate the call waiting feature.
CallWaitingOff Deactivate the call waiting feature.
AlwaysFwdOn/BusyFwdOn/NoAn- Activate an always/busy/no answer forward feature to xxx for the IP

Yealink SIP-T46S Specifications

General

Manual	Yes
Cables included	LAN (RJ-45)
Number of handles included	1 pc(s)
Mounting	Desk/Wall
Handset type	Wired handset
Product type	IP Phone
Product color	Black
Voice codecs	CNG, G.711Mu, G.711a, G.722, G.723.1, G.726, G.729ab, VAD, iLBC
Lines quantity	16 lines
Phonebook capacity	1000 entries
Number of VoIP accounts	16
Operating temperature (T-T)	-10 - 50 °C
Operating relative humidity (H-H)	10 - 95 %
Display diagonal	4.3 \
Display resolution	480 x 272 pixels
AC adapter input voltage	100 - 240 V
AC adapter output current	2 A
AC adapter output voltage	5 V
Dual-Tone Multi-Frequency (DTMF) modes	In-band, Out-of band, SIP info
Volume control	Digital
Number of programmable keys	10
USB 2.0 ports quantity	1
Ethernet LAN (RJ-45) ports	2
Networking standards	IEEE 802.3af
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet LAN interface type	Gigabit Ethernet
Supported network protocols	SIP v1, SIP v2, LLDP/CDP/DHCP, OpenVPN, IEEE802.1X, IPv6, FTP/TFTP/HTTP/HTTPS
Harmonized System (HS) code	85171800

Weight and Dimensions

Depth	213 mm
Width	244 mm
Height	185 mm
Package depth	255 mm
Package width	274 mm
Package height	128 mm
