Yealink SIP-T46S Administrator's Guide

Administrator’s Guide for SIP-T2 Series/T4 Series/T5 Series/CP920 IP Phones
508
Permitted
Values
http-HTTP
https-HTTPS
Default
http
Web UI
Applications > Broadsoft XSI > XSI Account > XSI Server Type
Parameter
account.X.xsi.port
[1]
<MAC>.cfg
Description
It configures the port of the Xtended Services Platform server.
Note: It works only if “bw.xsi.enable" is set to 1 (Enabled).
Permitted
Values
Integer from 1 to 65535
Default
80
Web UI
Applications > Broadsoft XSI > XSI Account > Port
Parameter
bw.xsi.enable
[2]
<y0000000000xx>.cfg
Description
It enables or disables the XSI authentication feature for the phone.
Permitted
Values
0-Disabled
1-Enabled
If it is set to 0 (Disabled), the following features are unavailable on the phone:
BroadWorks Anywhere
Remote Office
Line ID Blocking
Anonymous Call Rejection
Simultaneous Ring Personal
BroadSoft Directory
BroadSoft Call Log
Call Park Feature via XSI Mode
Call Waiting Feature via XSI Mode
Voice Messaging
Centralized Call Recording
Executive and Assistant
BroadWorks Mobility
Group Night Forwarding
Silent Alerting
Default
0
Parameter
sip.authentication_for_xsi <y0000000000xx>.cfg
Description
It configures the authentication mechanism for XSI access.
Note: It works only if “bw.xsi.enable” is set to 1 (Enabled).
Permitted
Values
0-User Login Credentials for XSI Authentication, the phone uses the XSI user ID and password for XSI
authentication.
1-SIP Credentials for XSI Authentication, the phone uses the XSI user ID, the register name and pass-

Yealink SIP-T46S Specifications

General

Manual	Yes
Cables included	LAN (RJ-45)
Number of handles included	1 pc(s)
Mounting	Desk/Wall
Handset type	Wired handset
Product type	IP Phone
Product color	Black
Voice codecs	CNG, G.711Mu, G.711a, G.722, G.723.1, G.726, G.729ab, VAD, iLBC
Lines quantity	16 lines
Phonebook capacity	1000 entries
Number of VoIP accounts	16
Operating temperature (T-T)	-10 - 50 °C
Operating relative humidity (H-H)	10 - 95 %
Display diagonal	4.3 \
Display resolution	480 x 272 pixels
AC adapter input voltage	100 - 240 V
AC adapter output current	2 A
AC adapter output voltage	5 V
Dual-Tone Multi-Frequency (DTMF) modes	In-band, Out-of band, SIP info
Volume control	Digital
Number of programmable keys	10
USB 2.0 ports quantity	1
Ethernet LAN (RJ-45) ports	2
Networking standards	IEEE 802.3af
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet LAN interface type	Gigabit Ethernet
Supported network protocols	SIP v1, SIP v2, LLDP/CDP/DHCP, OpenVPN, IEEE802.1X, IPv6, FTP/TFTP/HTTP/HTTPS
Harmonized System (HS) code	85171800

Weight and Dimensions

Depth	213 mm
Width	244 mm
Height	185 mm
Package depth	255 mm
Package width	274 mm
Package height	128 mm
