Yealink SIP-T46S Administrator's Guide

Administrator’s Guide for SIP-T2 Series/T4 Series/T5 Series/CP920 IP Phones
512
Permitted
Values
String within 99 characters
Default
Blank
Supported
Devices
All phones except T48G, T46G, T42G, T41P and T29G
Parameter
bw.virtual_user.1.xsi.password <MAC>.cfg
Description
It configures the password of virtual account for XSI access authentication.
Note: It works only if “bw.xsi.enable” is set to 1 (Enabled) and it is required only when “sip.au-
thentication_for_xsi” is set to 0 (User Login Credentials for XSI Authentication).
Permitted
Values
String within 99 characters
Default
Blank
Supported
Devices
All phones except T48G, T46G, T42G, T41P and T29G
Parameter
bw.virtual_user.1.xsi.host <MAC>.cfg
Description
It configures the IP address of the Xtended Services Platform server for the virtual account.
Note: It works only if “bw.xsi.enable” is set to 1 (Enabled).
Permitted
Values
IP address or domain name
Default
Blank
Supported
Devices
All phones except T48G, T46G, T42G, T41P and T29G
Parameter
bw.virtual_user.1.xsi.server_type <MAC>.cfg
Description
It configures the access protocol of the Xtended Services Platform server for the virtual account.
Note: It works only if “bw.xsi.enable” is set to 1 (Enabled).
Permitted
Values
HTTP or HTTPS
Default
Blank
Supported
Devices
All phones except T48G, T46G, T42G, T41P and T29G
Parameter
bw.virtual_user.1.xsi.port <MAC>.cfg
Description
It configures the port of the Xtended Services Platform server for the virtual account.
Note: It works only if “bw.xsi.enable” is set to 1 (Enabled).
Permitted
Values
Integer from 1 to 65535
Default
80
Supported
Devices
All phones except T48G, T46G, T42G, T41P and T29G
Parameter
account.X.bw_disp_code.Y
[1][2]
<MAC>.cfg
Description
It configures the disposition code which must match one of the codes configured on BroadWorks.
Permitted
Values
Integer from 1 to 2147483647

Yealink SIP-T46S Specifications

General

Manual	Yes
Cables included	LAN (RJ-45)
Number of handles included	1 pc(s)
Mounting	Desk/Wall
Handset type	Wired handset
Product type	IP Phone
Product color	Black
Voice codecs	CNG, G.711Mu, G.711a, G.722, G.723.1, G.726, G.729ab, VAD, iLBC
Lines quantity	16 lines
Phonebook capacity	1000 entries
Number of VoIP accounts	16
Operating temperature (T-T)	-10 - 50 °C
Operating relative humidity (H-H)	10 - 95 %
Display diagonal	4.3 \
Display resolution	480 x 272 pixels
AC adapter input voltage	100 - 240 V
AC adapter output current	2 A
AC adapter output voltage	5 V
Dual-Tone Multi-Frequency (DTMF) modes	In-band, Out-of band, SIP info
Volume control	Digital
Number of programmable keys	10
USB 2.0 ports quantity	1
Ethernet LAN (RJ-45) ports	2
Networking standards	IEEE 802.3af
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet LAN interface type	Gigabit Ethernet
Supported network protocols	SIP v1, SIP v2, LLDP/CDP/DHCP, OpenVPN, IEEE802.1X, IPv6, FTP/TFTP/HTTP/HTTPS
Harmonized System (HS) code	85171800

Weight and Dimensions

Depth	213 mm
Width	244 mm
Height	185 mm
Package depth	255 mm
Package width	274 mm
Package height	128 mm
