Yealink VCM38 Administrator's Guide

| Basic Settings | 130
2. Configure and save the following settings:
Parameter Description Configuration Method
Title Bar
Enable or disable the VCS
endpoint to hide the title bar
during a call.
• Show- the VCS endpoint
displays the title bar.
• Hide with UI- the VCS
endpoint displays the title
bar and then hide it after 5
seconds.
• Hide- the VCS endpoint
hides the title bar.
Default: Hide with UI.
Web user interface
Time Icon
Enable or disable the VCS
endpoint to hide the call time
during a call.
• Show- the VCS endpoint
displays the call time.
• Hide with UI- the VCS
endpoint displays the call
time and then hide it after five
seconds.
• Hide- the VCS endpoint
hides the call time.
Default: Hide with UI.
Web user interface
Mute Icon
Enable or disable the VCS
endpoint to hide the mute icon
( ) during a call.
• Show- the VCS endpoint
displays the mute icon.
• Hide with UI- the VCS
endpoint displays the mute
icon and then hide it after five
seconds.
• Hide- the VCS endpoint
hides the mute icon.
Default: Hide with UI.
Web user interface

Yealink VCM38 Specifications

General

Type	Conference microphone
Noise reduction	Yes
Microphone frequency	100 - 16000 Hz
Microphone sensitivity	-45 dB
Microphone pick-up range	6 m
Number of microphone arrays	8
Maximum sound pressure level (1kHz)	100 dB
Device interface	RJ-45
Connectivity technology	Wired
Maximum operating distance	40 m
Mounting type	Ceiling
Product color	Silver
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	5 - 90 %
Number of products included	1 pc(s)
Harmonized System (HS) code	85181000
Power source	DC/PoE
Sustainability certificates	CE, Federal Communications Commission (FCC), REACH, RoHS

Weight and Dimensions

Width	127.3 mm
Height	66.3 mm
