Yealink VCM38 Administrator's Guide

| Getting Started | 30
No. Name Description
19 Pound key Enter the pound key (#).
Related information
Using the Remote Control
VCC22 video conferencing camera
VCC22 is a video conferencing camera for VC880/VC800/PVT980. It adopts 12x optical zoom lens,
supports 1080P/60 frame full HD video, has OSMO and PTZ function, and possesses professional video
quality and environmental adaptability. You can connect up to 9 VCC22 video conferencing cameras to the
VC880/PVT980 video conferencing system, and 8 to VC800 video conferencing system.
The VCC22 camera can be panned (± 100 degrees range), tilted (± 30 degrees range) and supports 12 x
optical zoom, white balance and automatic gain.
• Front Panel of VCC22 Video Conferencing Camera
• Rear Panel of VCC22 Video Conferencing Camera
Front Panel of VCC22 Video Conferencing Camera
The LED indicator in front of the camera indicates different camera status.
Related information
LED Instructions of VCC22 Video Conferencing Camera

Yealink VCM38 Specifications

General

Type	Conference microphone
Noise reduction	Yes
Microphone frequency	100 - 16000 Hz
Microphone sensitivity	-45 dB
Microphone pick-up range	6 m
Number of microphone arrays	8
Maximum sound pressure level (1kHz)	100 dB
Device interface	RJ-45
Connectivity technology	Wired
Maximum operating distance	40 m
Mounting type	Ceiling
Product color	Silver
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	5 - 90 %
Number of products included	1 pc(s)
Harmonized System (HS) code	85181000
Power source	DC/PoE
Sustainability certificates	CE, Federal Communications Commission (FCC), REACH, RoHS

Weight and Dimensions

Width	127.3 mm
Height	66.3 mm
