Yealink VCM38 Administrator's Guide

| Getting Started | 38
Rear Panel of VCM38
Name Description
1 PoE Connect to the VC Hub/Phone port on the VCS
endpoint.
VCM34
VCM34 is a brand-new video conferencing microphone array which can work as the audio input device
for Yealink Video Conferencing System. Thanks to its built-in 3-microphone array and superior audio
technology, VCM34 owns a 20ft (6m) and 360° voice pickup range, regarding as an ideal solution for any
conference room that needs the best audio experience.
Front Panel of VCM34

Yealink VCM38 Specifications

General

Type	Conference microphone
Noise reduction	Yes
Microphone frequency	100 - 16000 Hz
Microphone sensitivity	-45 dB
Microphone pick-up range	6 m
Number of microphone arrays	8
Maximum sound pressure level (1kHz)	100 dB
Device interface	RJ-45
Connectivity technology	Wired
Maximum operating distance	40 m
Mounting type	Ceiling
Product color	Silver
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	5 - 90 %
Number of products included	1 pc(s)
Harmonized System (HS) code	85181000
Power source	DC/PoE
Sustainability certificates	CE, Federal Communications Commission (FCC), REACH, RoHS

Weight and Dimensions

Width	127.3 mm
Height	66.3 mm
