| Getting Started | 32

Right Side of VCH50 Cable Hub

Port Name Description

2 Audio Connect to the CP960 Conference phone via the provided

0.5m network cable.

Rear Panel of VCH50 Cable Hub

Port Name Description

3 MINI DP Connect to PC via Mini-DP cable for sharing contents.

4 HDMI Connect to PC via HDMI cable for sharing contents.

5 USB Insert a USB flash drive. USB flash drive can be used for

storing screenshots, recorded videos or captured packets.

Hardware of VCH51 Video Conferencing Hub

You can connect VCH51 to the computer for presenting. If you want to connect a PC to your system using

Ethernet cable, you need to connect the VCH50 video conferencing hub to your system. Connecting

VCH51 to the computer for presenting is not applicable to VP59.

• Left Side of VCH51 Cable Hub

• Right Side of VCH51 Cable Hub
