Yealink VCM38 Administrator's Guide

| Managing the Directory | 228
Parameter Description Configuration Method
LDAP Name Filter
Configure the name attribute for
LDAP searching.
Example: (|(cn=%)(sn=%))
Web user interface
LDAP Number Filter
Configure the number attribute
for LDAP searching.
Example: (|(telephoneNumber=
%)(mobile=%))
Web user interface
LDAP TLS Mode
Configure the connection mode
between the LDAP server and
the system.
• LDAP—Unencrypted
connection between LDAP
server and the system (port
389 is used by default).
• LDAP TLS Start- TLS/SSL
connection between LDAP
server and the system (port
389 is used by default).
• LDAPs- TLS/SSL connection
between LDAP server and
the system (port 636 is used
by default).
Default: LDAP
Web user interface
LDAP Server Address Configure the domain name
or the IP address of the LDAP
server.
Web user interface
Port
Configure the LDAP server port.
Default: 389.
Web user interface
LDAP User Name
Configure the user name used to
log into the LDAP server.
Note: the user name is
provided by the LDAP server
administrator. If the LDAP server
allows ‘anonymous’ to login,
you don’t need to provide the
user name to access the LDAP
server.
Web user interface

Yealink VCM38 Specifications

General

Type	Conference microphone
Noise reduction	Yes
Microphone frequency	100 - 16000 Hz
Microphone sensitivity	-45 dB
Microphone pick-up range	6 m
Number of microphone arrays	8
Maximum sound pressure level (1kHz)	100 dB
Device interface	RJ-45
Connectivity technology	Wired
Maximum operating distance	40 m
Mounting type	Ceiling
Product color	Silver
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	5 - 90 %
Number of products included	1 pc(s)
Harmonized System (HS) code	85181000
Power source	DC/PoE
Sustainability certificates	CE, Federal Communications Commission (FCC), REACH, RoHS

Weight and Dimensions

Width	127.3 mm
Height	66.3 mm
