7-2
IM 2558A-01EN
Internal Signal Output
CAUTION
Do not short or apply external voltage to the output.
French
ATTENTION
Ne court-circuitez pas la sortie et n’appliquez par de tension externe à cette dernière.
Connect to the corresponding external input terminals
on the other 2558A (see section 7.2).
Output Section (OSC OUTPUT)
Output voltage: 3 ± 0.1 Vrms, sinusoidal
Frequency range: 40 Hz to 1000 Hz
Output resistance: Approx. 50Ω
If the frequency is set to EXT1 or EXT2, these terminals output the signal connected to EXT OSC
INPUT.
