8-2
IM CW240E
8.1 Data Save
8.1.1 Data Save Destination
The CW240 can save data (measured data and set values) in a PC card or
internal memory.
Selection of the data save destination (PC card or internal memory) is made on
the Save 1/2 screen.
TOP
MENU
ENTER
ENTER
LIGHT
TOP
MENU
SAVE
A
RANGE
START
&STOP
ESC
ENTER
F
1
F
2
F
3
F
4
F
5
DISP COPY
RANGE
[ 1 Displaying the Save 1/2 screen
Using the right and left direction cursor key, select the Save tab
(highlighted).
[ 2 Selecting the data save destination
Using the up and down direction cursor key, select DATA SAVE
(highlighted).
SEE ALSO
For the data save destination-setting procedure, see 6.4.5, Setting Up the Data Sav-
ing Destination.
TIP
• The setting conditions (set values on the Setup screen) can be saved.
• For more information on setting files, see Section 9.6, Setting Files (Load/Save/
Delete/Name Change).
Chapter 8 Saving Measured Data
To Next Page
