YOKOGAWA CW240 - Turning on the Power Switch

3-22
IM CW240E
3.6 Turning ON the Power Switch
[ 1 Model Name Screen
When the power switch is turned ON, the CW240 displays the following startup screen for
approx. 2 seconds.
2 Message Screen
This screen displays the model, version number, the presence of options, and self-check
results.
CW240 Ver 1.00
FPGA Check OK
SDRAM Check OK
SRAM Check OK
Flash Disk Check OK
RTC Check OK
EEPROM Check OK
Setting Check OK
Option:Analog In/Out
3 When the self-check has been completed normally, the screen displayed when
you previously turned OFF the CW240 appears.
To switch to the Top Menu screen shown
on the left, press the TOP MENU key.
TOP
MENU
key
