10.3 Using a Printer
10.3.1 Connecting a Printer
Connecting the printer (optional) to the CW240 allows measured data or set
values saved in the CW240 main unit to be printed out.
● Printer Specifications
Model: 97010
Seiko Instrument, model DPU-414 printer
Specifications:
Printing method Thermo-sensitive serial dot type
Number of displayable digits 80
Character configuration 9 ⫻ 7 dot matrix
Printing speed 52.5 mm/sec
Paper width 112 mm
Connection:
Use the RS-232 port.
Cable D-sub 9-pin to D-sub 9-pin straight cable
(male) (female)
