YOKOGAWA CW240

App.2-8
IM CW240E
Each CH
Value
DC
Voltage
• For the average value, INST becomes AVE.
• For the maximum value, INST becomes MAX.
• For the minimum value, INST becomes MIN.
1P3W
3P3W
W
Var
deg
P1_INST(W)_3P Active power 1
P3_INST(W)_3P Active power 3
Q3_INST(Var)_3P Reactive power 3
Q1_INST(Var)_3P Reactive power 1
VA
S3_INST(VA)_3P Apparent power 3
S1_INST(VA)_3P Apparent power 1
PF3_INST_3P Power factor 3
PF1_INST_3P Power factor 1
PA3_INST(deg)_3P Phase angle 3
PA1_INST(deg)_3P Phase angle 1
W
P2_INST(W)_1P Active power 2
P1_INST(W)_1P Active power 1
Var
Q2_INST(Var)_1P Reactive power 2
Q1_INST(Var)_1P Reactive power 1
VA
S2_INST(VA)_1P Apparent power 2
S1_INST(VA)_1P Apparent power 1
PF2_INST_1P Power factor 2
PF1_INST_1P Power factor 1
deg
PA2_INST(deg)_1P Phase angle 2
PA1_INST(deg)_1P Phase angle 1
V
DC2_INST(V) DC voltage CH2
DC1_INST(V) DC voltage CH1
Category
Header Characters Unit
Normal Measurement Data (3P3W+1P3W)
Content
Appendix 2 File/Print Item Descriptions
