App.2-13
IM CW240E
Appendix
App
Setting Data
Header Characters Content Content
MODEL Model, identification characters
VERSION Version number
ID ID number
WIRING Wiring
FREQUENCY Fixed clock
SAMPLING Sampling method
SOURCE Frequency measurement element
U_RANGE Voltage range
VT VT ratio
STD_VOLT Standard voltage
HYSTERESISE Detection hysteresis
SWELL Detection voltage swell
DIP Detection voltage dip
INTERRUPTION Detection voltage interruption
Detection Data
Header Characters Content
NO Number
DATE
Detection date
TIME Detection time
TYPE
Detection type
CH Voltage CH
IN/OUT Detection start/end
U_INST(V)
Detection voltage rms value (V)
PERIOD_TIME Interval
yyyy/mm/dd
hh:mm:ss
nnn msec
SWELL : swell
DIP : dip
INTER : interruption
U1,U2,U3
U1_3P,U2_3P,U3_3P
U1_1P,U2_1P
IN : start
OUT: end
hhhh:mm:ss
nnn msec
Appendix 2 File/Print Item Descriptions
