YOKOGAWA CW240

App.2-16
IM CW240E
Category Header Characters Unit
Harmonic Measurement Data (excluding 3P3W+1P3W)
Content
***** INST(LOAD1) ***** to
***** INST(LOAD4) *****
Instantaneous value Loads 1 to 4
U1
Voltage
Voltage 1
I1
Current
Current 1
PElectric Power Electric power
ORDER
Order
Harmonic order
LEVEL
Level
Harmonic level
V, kV, MV
mA, A, kA, MA
mW, W, kW,
MW, GW, TW
CONT.Content
Harmonic content
%
PAPhase Angle Harmonic phase angle
deg
TOTALTotal Value Total value (1st to 50th order)
V, kV, MV
mA, A, kA, MA
mW, W, kW,
MW, GW, TW
THDF
THD-F
(Selection)
Total harmonic distortion factor
(THD-F)
%
THDR
THD-R
(Selection)
Total harmonic distortion factor
(THD-R)
%
***** AVE(LOAD1) ***** to
***** AVE(LOAD4) *****
Average value Loads 1 to 4
***** MAX(LOAD1) ***** to
***** MAX(LOAD4) *****
Maximum value Loads 1 to 4
***** MIN(LOAD1) ***** to
***** MIN(LOAD4) *****
Minimum value Loads 1 to 4
U2
Voltage 2
U3 Voltage 3
I2 Current 2
I3
I4
Current 3
Current 4
Appendix 2 File/Print Item Descriptions
