YOKOGAWA CW240

App.2-19
IM CW240E
Appendix
App
Category Header Characters Unit
Harmonic Measurement Data (3P3W+1P3W)
Content
***** INST(3P3W) ***** Instantaneous value 3P3W
U1
Voltage
Voltage 1
I1
Current
Current 1
P
Electric Power
Electric power
ORDEROrder Harmonic order
LEVELLevel Harmonic level
V, kV, MV
mA, A, kA, MA
mW, W, kW,
MW, GW, TW
V, kV, MV
mA, A, kA, MA
mW, W, kW,
MW, GW, TW
CONT. Content Harmonic content
%
PAPhase Angle Harmonic phase angle
deg
TOTALTotal Value
Total value
(1st to 50th order)
THDF
THD-F
(Selection)
Total harmonic distortion
factor (THD-F)
%
THDR
THD-R
(Selection)
Total harmonic distortion
factor (THD-R)
%
***** AVE(3P3W) *****
Average value 3P3W
***** MAX(3P3W) *****
Maximum value 3P3W
***** MIN(3P3W) *****
Minimum value 3P3W
***** INST(1P3W) *****
Instantaneous value 1P3W
***** AVE(1P3W) *****
Average value 1P3W
***** MAX(1P3W) *****
Maximum value 1P3W
***** MIN(1P3W) ***** Minimum value 1P3W
U2 Voltage 2
U3 Voltage 3
I2 Current 2
I3 Current 3
Appendix 2 File/Print Item Descriptions
