App.4-2
IM CW240E
When using the reactive power method
The harmonic power phase angle equations is
Pn
Qn
pn = tan
–1
(
)
θ
and Pn (active power) and Qn (reactive power) both have polarity. As a result,
φpn becomes 0 to ±180°, and the inflow/outflow and lead/lag of harmonics can
be determined, as indicated below.
• When –90 to 90° : Harmonics are flowing from the power supply to the
load.
• When –90 to –180° or 90 to 180°
: Harmonics are flowing from the load to the power
supply.
• When 0 to 180° : Lead phase
• When 0 to –180° : Lag phase
Appendix 4 Polarity (Harmonic Measurement)
