YOKOGAWA CW240 User Manual

3-16
IM CW240E
● Connecting Clamp-on Probes
When connecting a clamp-on probe to the CW240 main unit, connect the plug of
the clamp-on probe so that the groove in the plug agrees with the guide in the
CW240 main unit (that the H and L polarities are correctly connected).
● Types of Clamp-on Probes
Clamp-on probes that can be connected to the CW240 are available in the
following seven types. The CW240's current range setting changes depending
on the clamp-on probes in use.
CW240 Current Range
200 mA/500 mA/1 A/2 A
5 A/10 A/20 A/50 A
20 A/50 A/100 A/200 A
50 A/100 A/200 A/500 A
200 A/500 A/1000 A
Current range is selectable using a switch.
300 A/750 A/1500 A/3000 A
200 A/500 A/1000 A/2000 A
100 A/200 A/500 A/1000 A
Current range is selectable using a switch.
300 A/750 A/1500 A/3000 A
30 A/75 A/150 A/300 A
Model
96036 (for 2 A)
96033 (for 50 A)
96030 (for 200 A)
96031 (for 500 A)
96032 (for 700 A)
1000 A (for 5 minutes)
96034 (for 3000 A)
96034-1
96034_2
96034_3
96035 (for 3000 A)
96035_1
96035_2
CAUTION
When connecting a clamp-on probe, always check that the rating of the current
under test agrees with the rating of the clamp-on probe, including model num-
ber check.
3.4 Connecting Clamp-on Probes
