YOKOGAWA CW240 User Manual

5-8
IM CW240E
5.3 Ranges and Number of Digits
Range Configuration 2 (Using clamp-on probe 96033)
Voltage
Range
Wiring
1P2W 750.0 W 1.500 kW 3.000 kW 7.500 kW
1P3W 1.500 kW 3.000 kW 6.000 kW 15.00 kW
3P3W 1.500 kW 3.000 kW 6.000 kW 15.00 kW
3P4W 2.250 kW 4.500 kW 9.000 kW 22.50 kW
1P2W 1.500 kW 3.000 kW 6.000 kW 15.00 kW
1P3W 3.000 kW 6.000 kW 12.00 kW 30.00 kW
3P3W 3.000 kW 6.000 kW 12.00 kW 30.00 kW
3P4W 4.500 kW 9.000 kW 18.00 kW 45.00 kW
1P2W 3.000 kW 6.000 kW 12.00 kW 30.00 kW
1P3W 6.000 kW 12.00 kW 24.00 kW 60.00 kW
3P3W 6.000 kW 12.00 kW 24.00 kW 60.00 kW
3P4W 9.000 kW 18.00 kW 36.00 kW 90.00 kW
1P2W 5.000 kW 10.00 kW 20.00 kW 50.00 kW
1P3W 10.00 kW 20.00 kW 40.00 kW 100.0 kW
3P3W 10.00 kW 20.00 kW 40.00 kW 100.0 kW
3P4W 15.00 kW 30.00 kW 60.00 kW 150.0 kW
96033
Current Range
5.000 A 10.00 A 20.00 A 50.00 A
150.0 V
300.0 V
600.0 V
1.000 kV
Range Configuration 3 (Using clamp-on probe 96030)
1P2W 3.000 kW 7.500 kW 15.00 kW 30.00 kW
1P3W 6.000 kW 15.00 kW 30.00 kW 60.00 kW
3P3W 6.000 kW 15.00 kW 30.00 kW 60.00 kW
3P4W 9.000 kW 22.50 kW 45.00 kW 90.00 kW
1P2W 6.000 kW 15.00 kW 30.00 kW 60.00 kW
1P3W 12.00 kW 30.00 kW 60.00 kW 120.0 kW
3P3W 12.00 kW 30.00 kW 60.00 kW 120.0 kW
3P4W 18.00 kW 45.00 kW 90.00 kW 180.0 kW
1P2W 12.00 kW 30.00 kW 60.00 kW 120.0 kW
1P3W 24.00 kW 60.00 kW 120.0 kW 240.0 kW
3P3W 24.00 kW 60.00 kW 120.0 kW 240.0 kW
3P4W 36.00 kW 90.00 kW 180.0 kW 360.0 kW
1P2W 20.00 kW 50.00 kW 100.0 kW 200.0 kW
1P3W 40.00 kW 100.0 kW 200.0 kW 400.0 kW
3P3W 40.00 kW 100.0 kW 200.0 kW 400.0 kW
3P4W 60.00 kW 150.0 kW 300.0 kW 600.0 kW
20.00 A 50.00 A 100.0 A 200.0 A
150.0 V
300.0 V
600.0 V
1.000 kV
Voltage
Range
Wiring
96030
Current Range
