5-11
IM CW240E
Setting Ranges Using the Direct Keys
5
Range Configuration 8 (Using clamp-on probe 96034)
1P2W 15.00 kW 30.00 kW 75.00 kW 150.0 kW
1P3W 30.00 kW 60.00 kW 150.0 kW 300.0 kW
3P3W 30.00 kW 60.00 kW 150.0 kW 300.0 kW
3P4W 45.00 kW 90.00 kW 225.0 kW 450.0 kW
1P2W 30.00 kW 60.00 kW 150.0 kW 300.0 kW
1P3W 60.00 kW 120.0 kW 300.0 kW 600.0 kW
3P3W 60.00 kW 120.0 kW 300.0 kW 600.0 kW
3P4W 90.00 kW 180.0 kW 450.0 kW 900.0 kW
1P2W 60.00 kW 120.0 kW 300.0 kW 600.0 kW
1P3W 120.0 kW 240.0 kW 600.0 kW 1.200 MW
3P3W 120.0 kW 240.0 kW 600.0 kW 1.200 MW
3P4W 180.0 kW 360.0 kW 900.0 kW 1.800 MW
1P2W 100.0 kW 200.0 kW 500.0 kW 1.000 MW
1P3W 200.0 kW 400.0 kW 1.000 MW 2.000 MW
3P3W 200.0 kW 400.0 kW 1.000 MW 2.000 MW
3P4W 300.0 kW 600.0 kW 1.500 MW 3.000 MW
100.0 A 200.0 A 500.0 A 1.000 kA
150.0 V
300.0 V
600.0 V
1.000 kV
The model 96034 clamp-on probes allow a current range to be selected using a switch.
Model 96034_3 has a 1000 A range.
Voltage
Range
Wiring
96034_3
Current Range
Range Configuration 9 (Using clamp-on probe 96035)
1P2W 45.00 kW 112.5 kW 225.0 kW 450.0 kW
1P3W 90.00 kW 225.0 kW 450.0 kW 900.0 kW
3P3W 90.00 kW 225.0 kW 450.0 kW 900.0 kW
3P4W 135.0 kW 337.5 kW 675.0 kW 1.350 MW
1P2W 90.00 kW 225.0 kW 450.0 kW 900.0 kW
1P3W 180.0 kW 450.0 kW 900.0 kW 1.800 MW
3P3W 180.0 kW 450.0 kW 900.0 kW 1.800 MW
3P4W 270.0 kW 675.0 kW 1.350 MW 2.700 MW
1P2W 180.0 kW 450.0 kW 900.0 kW 1.800 MW
1P3W 360.0 kW 900.0 kW 1.800 MW 3.600 MW
3P3W 360.0 kW 900.0 kW 1.800 MW 3.600 MW
3P4W 540.0 kW 1.350 MW 2.700 MW 5.400 MW
1P2W 300.0 kW 750.0 kW 1.500 MW 3.000 MW
1P3W 600.0 kW 1.500 MW 3.000 MW 6.000 MW
3P3W 600.0 kW 1.500 MW 3.000 MW 6.000 MW
3P4W 900.0 kW 2.250 MW 4.500 MW 9.000 MW
300.0 A 750.0 A 1.500 kA 3.000 kA
150.0 V
300.0 V
600.0 V
1.000 kV
The model 96035 clamp-on probes allow a current range to be selected using a switch.
Model 96035_1 has a 3000 A range.
Voltage
Range
Wiring
96035_1
Current Range
5.3 Ranges and Number of Digits
