YOKOGAWA DPharp EJX***A Series User Manual

<3. Parameter Setting>
3-5
IM 01C25T01-06EN
See E
See D1
(next page)
• Detailed setup
• Review
• Sensors
• Signal condition
• Output condition
• Display condition
• Device information
• Test Key
D
• Pressure sensor
• SP sensor
• Temp sensor
• Snsr temp
• Amp temp
• Temp Unit
• Process variables
• Re-range
• Unit
• Xfer fnctn
• Pres Damp
• Low cut
• Low cut mode
• H/L Swap
• Bi-dir mode
• Quick resp
• T.Z. Cmp menu
• S.C. menu
• Pres
• Pres %
• SP
• Snsr temp
• Pres
• Pres %
• Unit
• Pres sensor trim
• SP
• SP %
• SP Unit
• A/G Select
• SP H/L Select
• SP sensor trim
• SP setup
• Keypad input
• Apply values
F0301-06.ai
• Process variables
• Analog output
• T.Z. Cmp mode
• Temp Zero
• S.C.
• Num of points
• Point setting
• X Start
• Y Start
• X End
• Y End
• Loop test
• Loop current mode
• D/A trim
• Scaled D/A trim
• Clear D/A trim
• AO alm typ
• Channel flags
• Auto recover
• AO lower limit
• AO upper limit
• Pres
• Pres %
• AO
• SP
• SP %
• Snsr temp
• Engr Disp
• Engr exp
• Engr Unit
• Digital Output
: HART 7 only
: EJX Series only
• LRV
• URV
• Unit
• LSL
• USL
• Min span
• Pres Zero trim
• Pres trim
• P LTP
• P UTP
• Pres trim info.
• P LTD
• P UTD
• Clear P snsr trim
• Static Pres trim
• SP LTP
• SP UTP
• SP trim info.
• SP Range
• SP Unit
• SP Damp
• SP A/G Setup
• SP H/L Select
• SP LTD
• SP UTD
• Clear SP snsr trim
• SP LRV
• SP URV
• SP Unit
• SP LSL
• SP USL
• SP Min Span
• Keypad input
• SP Apply values
• A/G Select
• Atm. Pres Value
HART 7
HART 7
HART 7
EJX
EJX
