YOKOGAWA DPharp EJX***A Series User Manual

<5. Parameter Summary>
5-11
IM 01C25T01-06EN
Function Label Item Contents Default value Handling *
1
SP setup A/G Select Gauge/Abs select for static
pressure
Gauge or Absolute Absolute WD
Atm. Pres Value Conversion coe󰀩cient 101.3 kPa WD
SP Apply values Rerange for static pressure “0%, 100%, or Exit” MD
SP Damp Damping time constant for SP 0.00 to 100.00 2.00 s WD
SP H/L Select H/L select for static pressure High or Low High WD
SP Min Span Minimum span for static pressure RD
SP LRV Lower range value for static
pressure
Within measurement range 0.0 MPa WD
SP LSL Lower sensor limit for static
pressure
RD
SP URV
*3
Upper range value for static
pressure
Within measurement range WD
SP USL Upper sensor limit for static
pressure
RD
Status Device Status Current operating status R
Status group 1 Device status information for
hardware
Display the hardware error R
Status group 2 Device status information for
hardware
Display the hardware error R
Status group 3 Device status information for
process
Display the process error
(Out of specication)
R
Status group 4 Device status information for
process
Display the process error
(Out of setting range)
R
Status group 5 Device status information for
process
Display the process error
(Alarm)
R
Status group 6 Device status information for data Display the setting error R
Status group 7 Device status information for data Display the setting error R
Status group 8 Device status information for data Display the diagnostic alarm R
Status group 9 Device status information for data Display the diagnostic alarm R
Status group 10
HART 7
Device status information for data Display the simulation mode R
Ext dev status
HART 7
Extended Device Status R
Time Stamp Time Stamp 00:00:00 R
Tag Tag Tag number 8 alphanumerics As specied W
Long tag
HART 7
Long tag Max 32 alphanumerics As specied W
Temperature
compensation
T.Z. Cmp mode Temperature compensation mode O󰀨 or On O󰀨 W
Temp Zero Zero shift compensation –99.999 to 99.999%/degC 0.000%/degC W
Temperature
sensor
Amp temp Amplier temperature R
Snsr temp Capsule temperature R
Transfer
function
Xfer fnctn Output mode Linear or Sq root As specied or
Linear
W
Units Unit Pressure, Di󰀨erential pressure unit As specied or
kPa
W
SP Unit Static pressure unit MPa WD
Temp Unit Temperature unit deg C, deg F, or Kelvin deg C W
Write
protection
menu
Enable wrt 10min Write protection release 8 alphanumerics M
New password User set password for write
protection
8 alphanumerics M
Write protect Write protection indicator Yes or No No R
*1: Handling:
R
=Read only,
W
=Read & Write,
M
=Method,
A
=Applicable for option code AL,
G
=Applicable for option code DG6,
D
=Applicable for di󰀨erential pressure transmitters. Do not change these parameters for pressure transmitters.
*2: Max three Burst Messages (Burst Message 1, Burst Message 2, Burst Message 3)
*3: The default value shows MWP (Maximum working pressure) of the capsule.
Since the working pressure limit varies according to the Model, refer to the General Specications section in each user’s manual.
*4: For output signal code J, refer to the section 3.3.18.
*5: These parameters may contain adjustment values based on the customer range calibration at the factory upon shipment.
When executing “Clear P sensor trim”, P LTD and P UTD will become “0”, and P LTP and P UTP will become the value of LRV and
URV respectively.
