B3.4 Operation
Once you have completed the setup described in Sections B3.1, “Setting Controller
Parameters,” B3.2, "Setting I/O Parameters," and B3.3, “Setting Operation Parameters”,
the module is ready for operation. Start module operation in manual or automatic mode
by writing to the RUN/STP and A/M/C registers. To operate in Manual mode, specify an
output level using the Manual Output (MOUT) register.
For information on SP number selection, remote set point, and other operation control
functions, see Section C7, "Operation Control."
Table B3.15 Operation Control Parameters
Data Position Number
Symbol Description Unit Data Range
Default
Value
Attribute Stored
See
Also
Loop1 Loop2 Loop3 Loop4
121 321 521 721 RUN/STP Run/stop selection None
0: Stop
1: Run
0 RW — C7.1
122 322 522 722 A/M/C
Automatic/manual
/cascade selection
*!
None
0: Automatic
1: Manual
2: Cascade (only
valid for the
even-numbered loop
in cascade control
mode)
0 RW —
C7.2
C7.4
124 324 524 724 RMT/LOC
Remote/local
selection
None 0: Local, 1: Remote 0 RW — C7.3
128 328 528 728 SPNO SP number selection None 1 to 4 1 RW — C4.1
133 333 533 733 RSP Remote set point
Industrial
unit
PRL to PRH PRL RW — C4.2
134 334 534 734 MOUT
Manual output
(for single output or
heating output in
heating/cooling
control)
%
OL to OH: for single
output;
0 to OH: for
heating/cooling
control
0 RW —
C7.2
C7.4
*1: The controller mode must be set to Cascade Control before the ‘Cascade’ option can be selected. Set the operation
control parameters of the even-numbered loop (loop 2 or 4) in cascade mode.
Table B3.16 Relationship between Operating Status, Operation Control, and Output Values
Operating
Status
Operation Control
Output Remarks
RUN/STP
/M/C
Stop 0
0
POUT (and POUTC)
This is the status immediately after power up. In Stop mode,
the stored value of the Preset Output parameter is output.
1
Automatic
1
0 HOUT (and COUT)
Manual 1 MOUT (and MOUTC)
To Next Page
