B2-4

IM 34M06H62-02E 2nd Edition : June 2008-00

B2.2.1 Common Process Data

These are basic process-related data common to all loops, including PV, control set

point, control output, and other constantly monitored process-related data.

Table B2.3 Common Process Data

Data

Position

Number

Symbol Description Unit Data Range

Default

Value

Attribute Stored

See

Also

1 PV.1

Process value

Industrial

unit

-5.0 to 105.0% of

(PRL to PRH)

— RO —

C3.

2 PV.2 — RO —

3 PV.3 — RO —

4 PV.4 — RO —

Control set point

11 CSP.1

Control set

point

Industrial

unit

PRL to PRH

— RO —

C4.

12 CSP.2 — RO —

13 CSP.3 — RO —

14 CSP.4 — RO —

Control output

21 HOUT.1

Control output %

OL to OH:

for single output

0 to OH:

for heating/cooling output

— RO —

C2.

C7.1

22 HOUT.2 — RO —

23 HOUT.3 — RO —

24 HOUT.4 — RO —

Cooling Control

output

31 COUT.1

Cooling Control

output

0 to OL:

for heating/cooling output

— RO —

C7.1

32 COUT.2 — RO —

33 COUT.3 — RO —

34 COUT.4 — RO —

Operating Status

41 RUN.STUS.1

Operating

Status

None

Each bit is on or off

depending on the status.

For details, see text

section under “See Also.”

— RO —

C10.

42 RUN.STUS.2 — RO —

43 RUN.STUS.3 — RO —

44 RUN.STUS.4 — RO —

Error Status

51 ERR.STUS.1

Error Status None

Each bit is on or off

depending on the status.

For details, see text

section under “See Also.”

— RO —

C10.

52 ERR.STUS.2 — RO —

53 ERR.STUS.3 — RO —

54 ERR.STUS.4 — RO —
