C2-6
IM 34M06H62-02E 2nd Edition : June 2008-00
C2.3 Output Terminal Selection
The output terminal selection (OUTSELn) parameters define whether each output
terminal outputs control output (HOUTn or COUTn) or analog output (AOUTn). Analog
output allows manual analog output, which simply outputs a specified analog value, and
is available only with F3CU04-1S. Use the OUTSELn parameters (n is 1-4 for
F3CU04-0S, and 1-8 for F3CU04-1S) to configure individual terminals.
Table C2.4 Output Terminal Selection Parameters (for F3CU04-0S)
Data Position
Number
Symbol Description
Default
V
alue
Relationship between Setting and Output
91 OUTSEL1 Output terminal 1 1 1 : HOUT.1 11 : COUT.1
2 : HOUT.2 12 : COUT.2
3 : HOUT.3 13 : COUT.3
4 : HOUT.4 14 : COUT.4
92 OUTSEL2 Output terminal 2 2
93 OUTSEL3 Output terminal 3 3
94 OUTSEL4 Output terminal 4 4
Table C2.5 Output Terminal Selection Parameters (for F3CU04-1S)
Data Position
Number
Symbol Description
Default
Value
Relationship between Setting and Output
91 OUTSEL1 Output terminal 1 1 1 : HOUT.1 21 : AOUT1
2 : HOUT.2 22 : AOUT2
3 : HOUT.3 23 : AOUT3
4 : HOUT.4 24 : AOUT4
11 : COUT.1 25 : AOUT5
12 : COUT.2 26 : AOUT6
13 : COUT.3 27 : AOUT7
14 : COUT.4 28 : AOUT8
92 OUTSEL2 Output terminal 2 2
93 OUTSEL3 Output terminal 3 3
94 OUTSEL4 Output terminal 4 4
95 OUTSEL5 Output terminal 5 11
96 OUTSEL6 Output terminal 6 12
97 OUTSEL7 Output terminal 7 13
98 OUTSEL8 Output terminal 8 14
The OUTSEL 1-8 settings must be enabled to take effect. For details on how to enable
settings, see Section B2.3, "How to Enable Settings."
For F3CU04-1S, an output terminal must be set to Analog Output (4-20 mA current
output) using the Output Type Selection (OUTPUT) parameter before it can be set to
output AOUTn using the Output Terminal Selection (OUTSELn) parameter. If an output
terminal is set to Open Collector using the Output Type Selection (OUTPUT) parameter,
and it is then set to output AOUTn, the open collector of that terminal is always 0 (off).
