C11-1
IM 34M06H62-02E 2nd Edition : June 2008-00
C11. Selecting Temperature Unit
This section describes how to set the temperature unit used with this module.
You may switch the temperature unit between C (Celsius) and F (Fahrenheit)
using switch SW1-1 located on the side of the module.
Figure C11.1 Input Type, Power Frequency, and Temperature Unit Selector Switches on the
Side of the Module
TableC11.1 Temperature Unit Selection
Temperature Unit Temperature Unit Selector Switch
Remarks
C OFF Factory setting
F ON
Always turn off the power before performing switch setup.
A change in the setting of the temperature unit selector switch is processed as a change
in input type, and thus causes the input/output parameters and the operation parameters
to be reset to default values. Perform parameter setup again, if required.
CAUTION
CAUTION
To Next Page
