YOKOGAWA F3CU04-1S User Manual

D2-3
IM 34M06H62-02E 2nd Edition : June 2008-00
(2) Any LED indicator other than RDY and 60 Hz is lit or flashing
If any LED indicator other than the RDY and 60 Hz LED indicators (e.g. ALM or ERR LED
indicator) is lit or flashing, an alarm or error has been detected. An input circuit may be
incorrectly connected, or the self-diagnosis function may have detected an internal error.
Follow the steps below to locate the cause.
- All loops with no sensor connected should be disabled using the controller mode
registers.
- For a loop configured for thermocouple or DC voltage input, no signal connection
must be made to its NC terminals, as shown in Section A4.3.2, "Terminal Wiring
Diagram." Otherwise an AD converter error may be detected.
- Check that register preset values are appropriate. See the table below.
Data Position Number
Symbol Content Check Items See Also
Loop 1 Loop 2 Loop 3 Loop 4
83 MD12 Controller mode All loops with no sensor connected must be
disabled.
C1
84 MD34
102 302 502 702 PV Process value Are values proper?
Check the values against PRL and PRH.
C3
108 308 508 708 RUN.STUS Operating status Is bit 15 set? If so, check ERR.STUS. C10.2
109 309 509 709 ALM.STUS Alarm status Are any of bits 0-3 set? If so, check the
corresponding alarm type, alarm setting, and
alarm hysteresis.
C8.1
110 310 510 710 ERR.STUS Error status Is any bit set? If so, check the indicated cause. C10.2
202 402 602 802 1.A1 Alarm 1 preset value If an alarm is detected, check its alarm conditions. C8.1
203 403 603 803 1.A2 Alarm 2 preset value
204 404 604 804 1.A3 Alarm 3 preset value
205 405 605 805 1.A4 Alarm 4 preset value
222 422 622 822 2.A1 Alarm 1 preset value
223 423 623 823 2.A2 Alarm 2 preset value
224 424 624 824 2.A3 Alarm 3 preset value
225 425 625 825 2.A4 Alarm 4 preset value
242 442 642 842 3.A1 Alarm 1 preset value
243 443 643 843 3.A2 Alarm 2 preset value
244 444 644 844 3.A3 Alarm 3 preset value
245 445 645 845 3.A4 Alarm 4 preset value
262 462 662 862 4.A1 Alarm 1 preset value
263 463 663 863 4.A2 Alarm 2 preset value
264 464 664 864 4.A3 Alarm 3 preset value
265 465 665 865 4.A4 Alarm 4 preset value
281 481 681 861 AL1 Alarm 1 type
282 482 682 862 AL2 Alarm 2 type
283 483 683 863 AL3 Alarm 3 type
284 484 684 884 AL4 Alarm 4 type
285 485 685 885 HY1 Alarm 1 hysteresis
286 486 686 886 HY2 Alarm 2 hysteresis
287 487 687 887 HY3 Alarm 3 hysteresis
288 488 688 888 HY4 Alarm 4 hysteresis
