C2-3
IM 34M06H62-02E 2nd Edition : June 2008-00
Table C2.1 Output-related Parameters (1/3)
Data Position Number
Symbol Description Unit Data Range
Default
Value
Attribute Stored
See Also
Loop1 Loop2 Loop3 Loop4
61 AOUT1
Output preset value %
-500 to 10500
(-5.00 to 105.00%)
0 RW —
C2.5
62 AOUT2 0 RW —
63 AOUT3 0 RW —
64 AOUT4 0 RW —
65 AOUT5 0 RW —
66 AOUT6 0 RW —
67 AOUT7 0 RW —
68 AOUT8 0 RW —
87 OUTPUT Output type selection None
Either open collector or analog output may
be selected for each terminal.
0 RW
C2.2
91 OUTSEL1
Output terminal selection
None
1-4: Heating outputs 1-4
11-14: Cooling outputs 1-4
21-28: Output preset values 1-8
1 RW
C2.3
92 OUTSEL2 2 RW
93 OUTSEL3 3 RW
94 OUTSEL4 4 RW
95 OUTSEL5 11 RW
96 OUTSEL6 12 RW
97 OUTSEL7 13 RW
98 OUTSEL8 14 RW
Table C2.1 Output-related Parameters (2/3)
Table C2.1 Output-related Parameters (3/3)
Data Position Number
Symbol Description Unit Data Range Default Value Attribute Stored
See Also
Loop1 Loop2 Loop3 Loop4
209 409 609 809 1.OH Upper output limit
%
-5.0 to 105.0% if OL ＜ OH. OL
is always output if OL OH.
1000 RW
C2.4.2
210 410 610 810 1.OL Lower output limit
0 (or 1000 for
heating/cooling
control)
RW
212 412 612 812 1.HYS
ON/OFF control
hysteresis
Industrial unit
0 to (PRH - PRL) (PRH - PRL) x 0.5% RW
C2.4.1
214 414 614 814 1.GAIN.C Cooling gain % 1 to 999 (1 to 999%) 100 RW
C2.4.3
215 415 615 815 1.HYS.C
Cooling ON/OFF control
hysteresis
Industrial unit
0 to (PRH - PRL) (PRH - PRL) x 0.5% RW
C2.4.4
216 416 616 816 1.DB Dead band Industrial unit
PID control: -10.0 to 10.0% of
(PRH PRL)
ON/OFF control: -50.0 to 50.0% of
(PRH - PRL)
0 RW
C2.4.3
C2.4.4
217 417 617 817 1.POUT Preset output % -50 to 1050 (-5.0 to 105.0%) 0 RW
C7.1
218 418 618 818 1.POUT.C Cooling preset output % -50 to 1050 (-5.0 to 105.0%) 0 RW
229 429 629 829 2.OH Upper output limit
%
-5.0 to 105.0% if OL ＜ OH. OL
is always output if OL OH.
1000 RW
C2.4.2
230 430 630 830 2.OL Lower output limit
0 (or 1000 for
heating/cooling
control)
RW
232 432 632 832 2.HYS
ON/OFF control
hysteresis
Industrial unit
0 to (PRH - PRL) (PRH - PRL) x 0.5% RW C2.4.1
234 434 634 834 2.GAIN.C Cooling gain % 1 to 999 (1 to 999%) 100 RW
C2.4.3
235 435 635 835 2.HYS.C
Cooling ON/OFF control
hysteresis
Industrial unit
0 to (PRH - PRL) (PRH - PRL) x 0.5% RW
C2.4.4
236 436 636 836 2.DB Dead band Industrial unit
PID control: -10.0 to 10.0% of
(PRH PRL)
ON/OFF control: -50.0 to 50.0% of
(PRH - PRL)
0 RW
C2.4.3
C2.4.4
237 437 637 837 2POUT Preset output % -50 to 1050 (-5.0 to 105.0%) 0 RW
C7.1
238 438 638 838 2.POUT.C Cooling preset output % -50 to 1050 (-5.0 to 105.0%) 0 RW
Data Position Number
Symbol Description Unit Data Range
Default
Value
Attribute Stored
See
Also
Loop1 Loop2 Loop3 Loop4
104 304 504 704 HOUT Control output %
OL to OH: for single output
0 to OH: for heating/cooling output
— RO —
C2
C.7.1
105 305 505 705 COUT Cooling control output % 0 to OL: for heating/cooling output — RO —
121 321 521 721 RUN/STP Run/stop selection None 0: Stop, 1: Run 0 RW — C7.1
122 322 522 722 A/M/C
Automatic/manual/cascade
selection
None
0: Automatic, 1: Manual
2: Cascade
0 RW —
C7.2
C7.4
126 326 526 726 EXOUT/OUT
External/normal output
selection
None
0: Normal output
1: External output
0 RW — C2.6
134 334 534 734 MOUT Manual output %
OL to OH: for single output
0 to OH: for heating/cooling output
0 RW —
C7.2
C7.4
135 335 535 735 MOUTC Manual cooling output % 0 to OL 0 RW —
136 336 536 736 EXOUT External output % -5.0 to 105.0% 0 RW — C2.6
141 341 541 741 OT Control type selection None
0: PID control
1: ON/OFF control
2: Heating/cooling PID control
3: Heating/cooling ON/OFF control
0 RW
C2.1
191 391 591 791 CT Cycle time Second
5 to 1200 (0.5 to 120.0 s)
300 RW
C2.4.2
192 392 592 792 CTc Cooling cycle time Second 300 RW
—
193 393 593 793 MVR Rate-of-change limit %/s
0: OFF, 1 to 100
(0.1 to 100.0% per second)
0 RW
C2.4.2
To Next Page
