Table C2.13 Parameters Related to Heating/Cooling PID Control (2/2)
Data Position Number
Symbol Description Unit Data Range
Default
Value
Attribute Stored
Loop 1 Loop 2 Loop 3 Loop 4
277 477 677 877 4.POUT Preset output %
-50 to 1050
(-5.0 to 105.0%)
0 RW 
278 478 678 878 4.POUT.C Cooling preset output %
-50 to 1050
(-5.0 to 105.0%)
0 RW 
The rate-of-change limit is disabled in heating/cooling PID control.
Table C2.14 Input Relays Related to Heating/Cooling PID Control
Input Relay Number
Xnn
*1
Symbol Description Data Range
Loop1 Loop2 Loop3 Loop4
X05 X13 X20 X29 HOUT.R Heating control output 0: OFF 1: ON
X06 X14 X21 X30 COUT.R Cooling control output 0: OFF 1: ON
*1  denotes the slot number where the module is installed.
