12-14 IM 04L20A01-01E
Isolation
Item Specifications
Insulation resistance Each terminal to ground terminal: 20 MΩ or greater (at 500 VDC)
Dielectric strength Power supply to ground terminal: 2300 VAC (50/60 Hz), 1 minute (excet for /P1 model)
Power supply to ground terminal: 500 VAC (50/60 Hz), 1 minute (for /P1 model)
Contact output terminal to ground terminal: 1600 VAC (50/60 Hz), 1 minute
Measuring input terminal to ground terminal: 1500 VAC (50/60 Hz), 1 minute
Between measuring input terminals: 1000 VAC (50/60 Hz), 1 minute (except for RTD input
terminals)
Between remote control terminal to ground terminal: 1000 VDC, 1 minute
Between pulse input terminal to ground terminal: 1000 VDC, 1 minute
Grounding resistance 100 Ω or less
Transport and Storage Conditions
Item Specifications
Ambient temperature –25°C to 60°C
Humidity 5% to 95% RH (No condensation is allowed).
Vibration 10 to 60 Hz, 4.9 m/s
2
maximum
Shock 392 m/s
2
maximum (while being packed)
Safety and EMC Standards
Item Specifications
CSA Certified by CSA22.2 No. 1010.1, Installation category (Overvoltage category) II
*1
, Pollution degree
2
*2
UL Certified by UL61010B-1 (CSA NRTL/C)
CE
EMC Complies with EN61326-1
Complies with EN61000-3-2
Complies with EN61000-3-3
Complies with EN55011 Class A Group 1
Low voltage Complies with EN61010-1, Measurement category II
*3
C-Tick Complies with AS/NZS2064 Class A Group 1
*1 “Installation category (Overvoltage category)” describes a number which defines a transient overvoltage condition. It implies
the regulation for impulse withstand voltage. “II” applies to electrical equipment which is supplied from the fixed installation
like distribution board.
*2 “Pollution degree” describes the degree to which a solid, liquid, or gas which deteriorates dielectric strength or surface
resistivity is adhering. “2” applies to normal indoor atmosphere. Normally, only non-conductive pollution occurs.
*3 Applies to measuring circuits connected to low voltage installation, and electrical instruments supplied with power from fixed
equipment such as electric switchboards.
12.6 General Specifications
