YOKOGAWA FX106 User Manual

App-19
IM 04L20A01-01E
App
Appendix
#3 Memory
Parameter Selectable Range or Selections Initial Value
Memory > Save Manual or Auto Auto
Memory > Data Display, E+D, or Event Display
Memory > Event > Sample rate FX103: 250 ms, 500 ms, 1 s, 2 s, 5 s, 10 s, 30 s, 250 ms
60 s, 120 s, 300 s, or 600 s
FX106/FX112: 1 s, 2 s, 5 s, 10 s, 30 s, 60 s, 120 s, 1 s
300 s, or 600 s
Memory > Event > Mode Free, Trigger, or Rotate Trigger
Memory > Event > Block 1, 2, 4, 8, or 16 1
Memory > Event > Data length 3 minutes to 31 days 1 h
Memory > Event > Pre-trigger 0, 5, 25, 50, 75, 95, or 100 0
Memory > Event > Trigger > Key On/Off On
Memory > Event > Trigger > External On/Off Off
Memory > Event > Trigger > Alarm On/Off Off
#4 Memory and Trend, Memory Timeup
Parameter Selectable Range or Selections Initial Value
Memory and trend > Meas CH/Math CH
1
Meas CH, Math CH
1
Meas CH
Memory and trend > First-CH Meas CH: 01 to 12, Math CH
1
: 31 to 42 01
Memory and trend > Last-CH Meas CH: 01 to 12, Math CH
1
: 31 to 42 01
Memory and trend > On/Off On/Off On
Memory timeup > Timeup type Off, Hour, Day, Week, or Month Off
Memory timeup > Date 1 to 28 1
Memory timeup > Time (hour) 0 to 23 0
1
/M1 or /PM1 option
#5 Aux, Time zone
Parameter Selectable Range or Selections Initial Value
AUX > Tag/Channel Tag or Channel Channel
AUX > Memory alarm Off, 1 h, 2 h, 5 h, 10 h, 20 h, 50 h, or 100 h 1 h (Off on models
with no drive)
AUX > Language English, Japanese, German, French, Chinese, English
Spanish, or Italian
AUX > Partial Use/Not Not
Time zone > Difference from GMT –1200 to 1200 0
Media FIFO On/Off Off, only for models
with a CF memory
card slot
#6 Keylock
Parameter Selectable Range or Selections Initial Value
Keylock > Use/Not Use/Not Not
Keylock > Password Up to 6 alphanumeric characters –
Keylock > Keys such as START Free or Lock Free
Keylock > ALARM ACK Free or Lock Free
Keylock > Math Free or Lock Free
Keylock > Write memory Free or Lock Free
Keylock > Media Free or Lock Free
#7 Key login
Parameter Selectable Range or Selections Initial Value
Key login > Use/Not Use/Not Not
Key login > Auto logout On/Off Off
Key login > UserID Use/Not Use/Not Not
Key login > Number 1, 2, 3, 4, 5, 6, or 7 1
Key login > On/Off On/Off On
Key login > User name Up to 16 alphanumeric characters user1
Key login > User ID Up to 4 alphanumeric characters 1
Key login > Password Up to 6 alphanumeric characters –
Key login > Enter setup Enable or Disable Enable
Appendix 6 List of Parameters
