1. Overview
1-8
TI 30A10A30-01E
1.3 Auto-ConfigurationAdapter(ACA)
ACA (MS-Code: GRVACA-677FA) is a USB memory for the Recommended Switch for saving/
loading the configuration to change from the default configuration.
If ACA is plugged-in, the Recommended Switch starts loading configuration automatically from
ACA during startup.
The configuration file can be backed-up on a file server, as the ACA is regarded as a USB
memory when connected to a computer.
ACA image is as shown below.
F010301.ai
Figure ACA image
For more information, see section 3.
1.4 Terminal Cable
A terminal cable (MS-Code: GRVCAB-678FA) is required for changing the configuration.
The terminal cable connects COM port of a computer to V.24 port of the Recommended Switch.
Command Line Interface (CLI) is available through the serial interface connection with VT100
compatible terminal software.
The Terminal Cable image is as shown below.
F010401.ai
Figure Terminal Cable image
For more information, see section 4.
Sep. 19, 2014-00
