1.1 Recommended Switch Models
1.1.1 Managed Switches
The list of Managed Switches is shown as below.
Table List of Managed Switches
Layer
Vnet/IP
BUS
MS-Code
(Vendermodelname)
Product
Family
Ports
Power
Supply
Operating
Temp.(°C)
Mounting
RJ-45 SFP P1 P2
L2SW
BUS1
BUS2
GRVSW-660FA
(RS40-0009CCCCEDBPYY)
RS40 9 (4) DC DC -40 to +70 DIN Rail
GRVSW-663FA
(MACH104-20TX-F)
MACH104 24 (4)
AC –
0 to +50
19” Rack
(1RU)
GRVSW-664FA
(MACH104-20TX-FR)
AC AC
GRVSW-665FA
(MAR1040-
4C4C4C4C9999EM9HPYY)
MAR1040
16 (16)
AC –
-40 to +70
19” Rack
(1RU)
GRVSW-666FA
(MAR1040-
4C4C4C4C9999EMMHPYY)
AC AC
GRVSW-667FA
(MAR1040-
4C4C4C4C9999ELLHPYY)
DC DC
L3SW
BUS1
GRVSW-668FA
(MAR1040-
4C4C4C4C9999EM9HRY1)
16 (16)
AC –
-40 to +70
19” Rack
(1RU)
GRVSW-669FA
(MAR1040-
4C4C4C4C9999EMMHRY1)
AC AC
GRVSW-670FA
(MAR1040-
4C4C4C4C9999ELLHRY1)
DC DC
BUS2
GRVSW-671FA
(MAR1040-
4C4C4C4C9999EM9HRY2)
16 (16)
AC –
-40 to +70
19” Rack
(1RU)
GRVSW-672FA
(MAR1040-
4C4C4C4C9999EMMHRY2)
AC AC
GRVSW-673FA
(MAR1040-
4C4C4C4C9999ELLHRY2)
DC DC
Note: Each SFP port is for dual purpose (RJ-45/SFP) combo port.
When an SFP module is installed in a combo port, the port automatically serves as an SFP interface. (Combo port works as RJ-
45 or SFP interface exclusively.)
The Recommended Switches work in the same configuration for RJ-45 or SFP interface.
Note: An AC power cable is not included. Please prepare AC power cable allowed to be used in the local region.
Models of the Managed Switches are categorized in three product families of which images are
as shown below.
F010101.ai
RS40 Family MACH104 Family MAR1040 Family
Figure DeviceimagesbytheproductfamilyoftheManagedSwitches
