Page #41 background imageLoading...
Page #41 background image
4.CongurationSetup
4-8
TI 30A10A30-01E
4.3.3 Confirmportstatus(showportall)
To confirm all port status, use “show port all” command.
This command is available in “Privileged Exec” mode or “User Exec” mode.
A sample display of “show port all” command execution is as shown below.
F040303.ai
(Hirschmann MACH) #show port all
Admin Physical Physical Link Link Cable-Cross Flow Device VLAN
Intf Type Mode Mode Status Status Trap PhysMode Fix Mode status Prio
------ ------ ------- ---------- ---------- ------ ------- ------------ ------- ------- ----
1/1 Enable Auto 1000 Full Up Enable Disable Enable Ignore 0
1/2 Enable Auto 1000 Full Up Enable Disable Enable Ignore 0
1/3 Enable Auto 100 Full Up Enable Disable Enable Ignore 0
1/4 Enable Auto 100 Full Up Enable Disable Enable Ignore 0
1/5 Enable Auto 1000 Full Up Enable Unsupported Enable Ignore 0
1/6 Enable Auto Down Enable Disable Enable Ignore 0
1/7 Enable Auto Down Enable Disable Enable Ignore 0
1/8 Enable Auto Down Enable Disable Enable Ignore 0
1/9 Disable Auto Down Enable Disable Enable Ignore 0
1/10 Disable Auto Down Enable Disable Enable Ignore 0
1/11 Disable Auto Down Enable Disable Enable Ignore 0
1/12 Disable Auto Down Enable Disable Enable Ignore 0
1/13 Disable Auto Down Enable Disable Enable Ignore 0
1/14 Disable Auto Down Enable Disable Enable Ignore 0
1/15 Disable Auto Down Enable Disable Enable Ignore 0
1/16 Disable Auto Down Enable Disable Enable Ignore 0
Figure Exampleof“showportall”commanddisplay
Key parameters in the above display are explained as below.
Admin Mode
The port control administration state is displayed as follows.
[Enable]: This port is available.
[Disable]: This port is not available.
The default value is Enable for all ports. By using “shutdown” command, it can be changed to
Disable. (See section 4.3.6)
The above sample display indicates that the ports 9 to 16 are disabled as unused ports.
Physical Mode
The configuration of link speed and duplex mode are indicated as follows.
[Auto]: Auto-negotiation
[10 Half]: 10Mbps, Half duplex
[10 Full]: 10Mbps, Full duplex
[100 Half]: 100Mbps, Half duplex
[100 Full]: 100Mbps, Full duplex
The default value is set as [Auto] for all ports. For Vnet/IP, the auto-negotiation should always be
used.
Sep. 19, 2014-00
