Page #51 background imageLoading...
Page #51 background image
Appendix1.Defaultconguration
App.1-1
TI 30A10A30-01E
Appendix1.Defaultconfiguration
The Recommended Switches are provided with the customized default configuration for Vnet/IP
to connect to Vnet/IP network as described in the summary below.
For Recommended L2SW, the customized default configuration is as shown below.
Auto-negotiation: Enable
Auto MDI/MDI-X (cable crossing): Enable
IGMP Snooping: Disable
STP (RSTP): Disable
For Recommended L3SW, the customized default configuration is as shown below.
The default configuration allows the L3SW to connect Vnet/IP domain to each port directly.
Auto-negotiation: Enable
Auto MDI/MDI-X (cable crossing): Enable
STP (RSTP): Disable
Port based routing: Enable
IP address assigned each port: See following table.
Routing protocol: RIP
Sprit horizon for RIP: Enable (Simple mode)
RIP update-timer: 1 second
RIP send version: RIP2 (RIP1 compatible mode)
RIP receive version: Both RIP1 and RIP2
Multi-cast routing: Enable
IGMP: Enable
Multi-cast routing protocol: PIM-DM
Table DefaultIPaddressassignedtoeachportofaRecommendedL3SW
ForBUS1 ForBUS2
Port 1 192.168.1.253 192.168.129.253
Port 2 192.168.2.253 192.168.130.253
Port 3 192.168.3.253 192.168.131.253
Port 4 192.168.4.253 192.168.132.253
: : :
Port 15 192.168.15.253 192.168.143.253
Port 16 192.168.16.253 192.168.144.253
To modify the configuration of Recommended Switch, use CLI through V.24 serial port.
HiDiscovery, a tool supported by Hirschmann, is not available for the customized default
configuration to harden the security.
The default system alarm condition for FAULT signal contact is power failure.
The FAULT signal contact becomes open when the power supply fails. In case of a redundant
power unit model, the FAULT LED glows in RED when one power unit fails.
Sep. 19, 2014-00
