4.CongurationSetup
4-1
TI 30A10A30-01E
4. ConfigurationSetup
InatypicalVnet/IPnetworkdesignbasedonthe“Vnet/IPNetworkconstructionguide,”
ManagedSwitchesrequirenomodificationfromthedefaultconfigurationexceptforsome
applications.
ThissectiondescribessomebasicCommandLineInterface(CLI)Commandsforsetting
upandconfirmingtheVnet/IPconfiguration.
TheManagedSwitchesalsosupportmanyotherCLIcommandsnotdescribedinthis
document.Formoreinformation,refertotheCLIReferenceManualintheattacheddisc
media of the Managed Switch.
ThisisnotapplicabletotheUnmanagedSwitch.
4.1 Preparationforsetting
For CLI control, connect a Managed Switch to a computer using a terminal cable.
Use a terminal software such as “Teraterm” to emulate VT-100 terminal with the computer. The
connection setup parameters for the terminal software are as shown below.
Speed: 9600 bps
Data: 8 bit
Parity: None
Stopbit: 1 bit
Handshake: None
Several of the commands may display many and/or long line of response messages. For the
terminal software, the recommended display setup is as shown below
Expand the terminal window size to approximately 120 columns.
Expand the scroll buffer size to approximately 10000 lines.
F040101.ai
V.24USB
AufkleberMAC-Adresse
P
FAULT
FAULT
Sb
RM
5
6
7
8
1 3
2 4
9 11
10 12
13 15
14 16
17 19
18 20
21 23
22 24
MA CH 104-2 0TX -F
Connect COM port of a computer to V. 24 port of the Managed
Switch with the terminal cable.
Computer as a setup tool
Use a Connection setup for terminal
software on the computer as below.
- Speed: 9600 bps
- Data: 8 bit
- Parity: None
- Stopbit: 1 bit
- Hardshake: None
Use a USB-Serial converter if the computer
has no COM port.
Figure Connection for CLI control
Sep. 19, 2014-00
