Page #27 background image
2.HardwareSpecications
2-13
TI 30A10A30-01E
Device status LED
The device status LED functions are as shown below.
Table DeviceStatusLEDFunction(SPIDERIIFamily)
LED name Reaction Device Status
P (Power)
ON (Green) Normal Operation
OFF All power fail
SFPportstatusLEDs
Port status LEDs for F/O ports on the device’s top edge of the front display port-related
information.
Table SFPportstatusLEDfunction(SPIDERIIFamily)
LED Name Reaction Meaning
LS/DA (*1) On (Green) Valid Connection
Flashing (Green) Data Traffic
OFF No valid connection
*1: Link Status/Data Access
RJ-45portstatusLEDs
The green and yellow LEDs at the individual port display port-related information.
Table SFPportstatusLEDfunction(SPIDERIIFamily)
LED name Reaction Meaning
LS/DA (*1) ON (Green) Valid connection
Flashing (Green) Data traffic
OFF No valid connection
SP (*2) OFF No valid connection
Flashing one time a period (Yellow) 10 Mbit/s connection
Flashing 2 times a period (Yellow) 100 Mbit/s connection
Flashing 3 times a period (Yellow) 1000 Mbits/s connections
*1: Link Status/Data Access
*2: Link Speed
SFPport
SFP port has a plug-in slot for an SFP module.
Plug the SFP module into the slot to use Vnet/IP optical connection.
RJ-45port
RJ-45 port connects Vnet/IP stations or other equipment with UTP cable.
Dec. 26, 2016-00
