  Appendix1.Defaultconguration
App.1-8
TI 30A10A30-01E
 MAR1040(L3SW)familydefaultconfiguration
This is an example of the Recommended L3SW for BUS1 display.
As for the Recommended L3SW, two types are available with different default configuration for
BUS1 and BUS2. The difference is the IP address assigned to each port.
See the default IP address list described at the top of this appendix.
Therunning-configonMAR1040(LS3W)familydefaultconfiguration(1/3)
F0A0107.ai
(Hirschmann MACH) #show running-config
!Current Configuration:
!Customized factory setting active
!
!Parameter string escape handling \, 1
!Characters to be preceded with escape char (\): \, !, ", ', ?
!System Description "Hirschmann MACH"
!System Version L3P-06.0.03 Build: 2011-03-23 20:34
vlan database
exit
network protocol none
network protocol hidiscovery off
!RMA operation
!RMA entry
configure
!
interface 1/1
routing
ip address 192.168.1.253 255.255.255.0
ip rip
ip rip send version rip1c
ip igmp
ip pimdm mode
exit
interface 1/2
routing
ip address 192.168.2.253 255.255.255.0
ip rip
ip rip send version rip1c
ip igmp
ip pimdm mode
exit
(Snip) interface 1/3 to 1/15 --- repeating the same setting.
Refer to the default IP address table
interface 1/16
routing
ip address 192.168.16.253 255.255.255.0
ip rip
ip rip send version rip1c
ip igmp
ip pimdm mode
exit
