Page #66 background imageLoading...
Page #66 background image
Appendix 2. VLAN-based routing
App.2-6
TI 30A10A30-01E
VLAN-basedroutingconfiguration(2/4)
F0A0209.ai
interface 1/1
set igmp forward-all
vlan pvid 11
vlan participation exclude 1
vlan participation include 11
exit
Snipinterface 1/2 to 1/4 --- repeating the same setting.
interface 1/5
set igmp forward-all
vlan pvid 12
vlan participation exclude 1
vlan participation include 12
exit
Snipinterface 1/6 to 1/8 --- repeating the same setting.
interface 1/9
set igmp forward-all
vlan pvid 13
vlan participation exclude 1
vlan participation include 13
exit
Snipinterface 1/10 to 1/12 --- repeating the same setting.
interface 1/13
set igmp forward-all
vlan pvid 14
vlan participation exclude 1
vlan participation include 14
exit
Snipinterface 1/14 to 1/16 --- repeating the same setting.
interface 9/1
ip address 192.168.1.253 255.255.255.0
ip rip
ip rip send version rip1c
ip igmp
ip pimdm mode
exit
Snipinterface 9/2 to 9/4 --- repeating the same setting except for IP address.
Sep. 22, 2011-00
