FCnf
Outputs Setting Data
Outputs the recorder setting data.
Syntax
FCnf,p1
p1
Operation
ALL
Read all settings.
IO
Read I/O settings.
MATH
Read Math settings.
COMM
Read communication
settings.
GROUP
Read display group
settings.
IP
Read IP address settings.
SECURITY
Read security settings.
MULTIBATCH
Read multi batch settings.
CONTROL
Read control settings.
CALIB
Read calibration correction
settings.
SERVER
Read Ethernet server
related settings.
INSTRU
Read device information
settings.
OTHERS
Read settings other than
above.
You can specify multiple items in the list above.
Separate each item with a colon (see the
example).
Example Read I/O and Math settings.
FCnf,IO:MATH
Description
• If you omit p1, all settings will be read.
• The setting data is output as the responses to the
command queries. The following table lists p1 values
(setting category) and the corresponding commands.
Setting Category and Target Commands
Settting
category
Command
IO SModeAI, SModeAICurrent, SModeDI,
SModePID, SScaleOver, SBOLmtAI,
SBOLmtAICurrent, SRangeAI,
SRangeAICurrent, SRangeDI,
SRangePulse, SRangeDO, SRangeAO,
SMoveAve, SFilter, SBurnOut, SRjc,
SAlarmIO, SAlmHysIO, SAlmDlyIO,
STagIO, SColorIO, SZoneIO, SScaleIO,
SBarIO, SPartialIO, SBandIO,
SAlmMarkIO, SValueIO, SPresetAO
MATH SMathBasic, SKConst, SWconst,
SRangeMath, STlogMath, SRolAveMath,
SAlarmMath, SAlmHysMath,
SAlmDlyMath, STagMath, SColorMath,
SZoneMath, SScaleMath, SBarMath,
SPartialMath, SBandMath,
SAlmMarkMath, SReport, SRepData,
SRepTemp, SRepCh, SDigitalSign,
SRepBatchInfo
COMM SRangeCom, SValueCom, SWDCom,
SAlarmCom, SAlmHysCom, SAlmDlyCom,
STagCom, SColorCom, SZoneCom,
SScaleCom, SBarCom, SPartialCom,
SBandCom, SAlmMarkCom
GROUP SGroup, STripLine, SSclBmp,
SDualGroup
IP SIpAddress, SDns, SDhcp
SECURITY SKdc, SSecurity, SOpePass,
SOpeLimit, SUser, SUserLimit,
SSignIn, SSignInTitle, SSignInLimit,
SBTPassword, SWebCustomMenu,
SWebTimeOut, SSessionSecurity
MULTIBATCH SMltTextField, SMltFileHead,
SMltFileName, SMltGroup,
SMltTripLine, SMltSclBmp
CONTROL SCtrlMode, SCtrlScan, SCtrlAction,
SCtrlType, SCtrlLoopAction,
SCtrlSPPID, SCtrlALNo, SCtrlAlmMode,
SCtrlDIRegist, SCtrlRelay,
SCtrlRangeAI, SCtrlBurnOut,
SCtrlRjc, SCtrlFilter, SCtrlCalibAI,
SCtrlRangeAO, SCtrlSpritAO,
SCtrlOutput, SCtrlRangePV,
SCtrlPVSwitch, SCtrlCalc,
SCtrlFilterSP, SCtrlRatioSP,
SCtrlBiasSP, SCtrlErrPreOut,
SCtrlOutLimit, SCtrlAlarm,
SCtrlAlarmVal, SCtrlSP,
SCtrlSPGradient, SCtrlPIDNo,
SCtrlRefPoint, SCtrlRHys,
SCtrlRefDEV, SCtrlPIDPb, SCtrlPIDTI,
SCtrlPIDTD, SCtrlPIDPara,
SCtrlRefPb, SCtrlRefTI,
SCtrlRefTD, SCtrlRefPara,
SCtrlDetail, SCtrlOutRatio,
SCtrlAtDetail, SCtrlAntiReset,
SCtrlOvershoot, SCtrlGroupSW,
SCtrlGroupName, SCtrlGroupSplit,
SCtrlGroup, SCtrlTag, SCtrlDispDV,
SCtrlBackColor, SCtrlOutOperate,
SPrgColor, SPrgDispDetail,
SCtrlEventAct, SLogicMath, SWConst
CALIB SCalibIO, SSchedule, SScheduleText
SERVER SServerEncrypt, SServer,
SDarwinCnvCh, SDarwinPortLimit
INSTRU SBTID, SInstruTag
• For the output format, see page 2-158.
