2.10.22 Control Summary (FLog)
The output in response to the command “FLog,CTRL” is shown below.
Syntax
EA<crlf>
yyyy/mo/dd_hh:mm:ss_aaa…a_sss…s<crlf>
…
EN<crlf>
yyyy/mo/dd_hh:mm:ss
Time of control occurrence
yyyy
Year (1900 to 2099)
mo
Month (01 to 12)
dd
Day (01 to 31)
hh
Hour (00 to 23)
mm
Minute (00 to 59)
ss
Second (00 to 59)
aaa…a
Name (up to 13 characters)
Pattern number_loop number_type
Pattern number Up to 2 characters
Loop number Up to 4 characters
Type Up to 5 characters
If the maximum number of characters is not used,
unused characters become spaces.
sss…s
Status (up to 12 characters)
Name State Description
Loop number
LOCAL
Control operation changed to local.
REMOTE
Control operation changed to remote.
PROGRAM
Control operation changed to
program.
AUTO
Control operation changed to auto.
MANUAL
Control operation changed to manual.
CASCADE
Control operation changed to
cascade.
RUN
Run control operation
STOP
Stop control operation
AT**_ON
Auto-tuning start
**: PID number (value) or "R"
AT OFF
Auto-tuning stop
Pattern number
PROG RUN
Program operation run
PROG RESET
Program operation stop
HOLD ON
Program operation hold start
HOLD OFF
Program operation hold release
WAIT ON
Program operation wait start
WAIT OFF
Program operation wait release
ADVANCE
Program operation advance execution
Pattern number_loop number_type
PVE**_ON
PV event occurrence in program
operation
**: Event number (value)
PVE**_OFF
PV event release in program
operation
**: Event number (value)
Pattern number
TME**_ON
Time event occurrence in program
operation
**: Event number (value)
TME**_OFF
Time event release in program
operation
**: Event number (value)
2.10 ASCII Output Format
