Commands and Responses
2
2.10.8 Recorder status (FStat)
The output in response to the command “FStat,0” is shown below.
Syntax
EA<crlf>
aaa.bbb.ccc.ddd<crlf>
EN<crlf>
The output in response to the command “FStat,1” is shown below.
Syntax
EA<crlf>
aaa.bbb.ccc.ddd.eee.fff.ggg.hhh<crlf>
EN<crlf>
aaa
Status information 1 (see table below)
bbb
Status information 2 (see table below)
ccc
Status information 3 (see table below)
ddd
Status information 4 (see table below)
eee
Status information 5 (see table below)
fff
Status information 6 (see table below)
ggg
Status information 7 (see table below)
hhh
Status information 8 (see table below)
Status Information 1
Bit Name Description
0 Under control Set to 1 while the recorder is under control.
1 Memory sampling Set to 1 during recording
2 Computing Set to 1 while computation is in progress.
3 Alarm activated Set to 1 when an alarm is activated.
4 Accessing medium Set to 1 while the SD medium is being accessed.
5 E-mail started Set to 1 while the e-mail transmission has been started.
6 Buzzer activated Set to 1 when the buzzer is activated.
7 Re-transmitting Set to 1 while re-transmitting.
Status Information 2
Bit Name Description
0 - -
1 - -
2 Memory end Set to 1 when the free space in the external memory is low.
3 Touch operation
login
Set to 1 when a user is logged in through touch operation.
4 User lock out
present
Set to 1 when a user lock out occurs, and remains at 1 until
user locked ACK is issued (only when the advanced security
function (/AS) enabled).
5 - -
6 Measurement
error
Set to 1 while measurement errors are detected on an AI
module or when a burnout has occurred.
7 Communication
error
Set to 1 when a Modbus master, Modbus client, WT
communication, or SLMP communication error has occurred.
Status 3 and 4 are edge operations. They are cleared when read.
