YOKOGAWA GX10 User Manual

2-91
IM 04L51B01-17EN
Commands and Responses
1
2
App
SPrgColor
Program Control Loop Color
Sets the loop color
Syntax
SPrgColor,p1,p2,p3,p4
p1
Loop number
p2
R value of RGB colors (0 to 255)
p3
G value of RGB colors (0 to 255)
p4
B value of RGB colors (0 to 255)
Query
SPrgColor [,p1] ?
Example
Description
• This command can be used when a PID control
module is installed and the program control function (/
PG option) is enabled.
For details on RGB values, see "Description" of the
SColorIO command.
SPrgDispDetail
Auto Message Printout, Automatic Switch
To Program Operation Display, Other
Display Settings
Sets the detail settings for auto message printout, display
switch, and start of program operation to On or Off.
Syntax
SPrgDispDetail,p1,p2,p3
p1
Program Run/Reset message
(Off, On)
Off
Messages are not
displayed.
On
Messages are displayed.
p2
Automatic switch to program operation
display (Off, On)
Off
Not switched to the program
operation display
On
Switched to the program
operation display
p3
Detail settings at start of program
operation (Off, On)
Off
Detail settings are not used
(default value).
On
Detail settings are used.
Query
SPrgDispDetail [,p1] ?
Example Set Program Run/Reset message to On,
automatic switch to program operation display
to Off, and Program RUN detail settings to On.
SPrgDispDetail,On,Off,On
Description
• This command can be used when a PID control
module is installed and the program control function (/
PG option) is enabled.
• p3 is a setting to set the start segment number and
starting time of program operation at the start of
program operation.
SCtrlEventAct
Control Event Action
Sets a control event action
When p2 (type) is set to Off
Syntax
SCtrlEventAct,p1,p2
p1
Registration number (1 to 100)
p2
Type (Off)
When p2 (type) is set to DI, DO, or internal switch
Syntax
SCtrlEventAct,p1,p2p3,p4,p5,p6,p7,
p8,p9
p1
Registration number (1 to 100)
p2
Type (DI, DO, SW)
DI
DI
DO
DO
SW
Internal switch
p3
Number
When P2=SW: 1 to 100
When P2=DI or DO: 0001 to 6932
p4
Input/output type (In, Out)
In
Varies depending on P2
(DI, DO, SW). See the table
below.
Out
p5
Status output content or operation content
Varies depending on P2 (DI, DO, SW). See
the table below.
For operation with p5=SELECT (hold, advance, start
of program operation, stop of program operation)
p6
Pattern type (PATTERN_NO, WCONST)
PATTERN_
NO
Program pattern number
WCONST
Variable constant W
p7
Pattern number
p8
Loop type (LOOP_NO, WCONST)
LOOP_NO
Loop number
WCONST
Variable constant W
p9
Loop number
When p5 is set to a value other than those above
(table below)
p6
Empty
p7
Element number corresponding to p5
Loop number
PV/time event number (1 to 32)
Query SCtrlEventAct [,p1]?
Example Set All loop control operation to stop when the
internal switch number (SW1) becomes 0 to 1.
Use Control event action number 1.
SCtrlEventAct,1,SW,1,In,ALL_LP_
STOP_ACT
Description
• This command can be used when a PID control
module is installed and the program control function (/
PG option) is enabled.
• If you need multiple channels for p2 (event type) and
p5 (action), use DI/DO/SW in the same module. The
table below shows the number of used channels.
2.4 Setting Commands
