YOKOGAWA GX10 User Manual

2-158
IM 04L51B01-17EN
2.10.26 Setting Data (FCnf)
The output in response to the command “FCnf” is shown below.
Syntax
EA<crlf>
<Response to a setting query>
EN<crlf>
The setting data is output in the format of the response to a setting query.
2.10.27 Decimal Place and Unit Information (FChInfo)
The output in response to the command “FChInfo” is shown below.
Syntax
EA<crlf>
s_cccc_uuuuuuuuuu,pp<crlf>
s_cccc_uuuuuuuuuu,pp<crlf>
s_cccc_uuuuuuuuuu,pp<crlf>
EN<crlf>
s
Data status
N
Normal
D
Differential input
S
Skip
cccc
Channel number (I/O channel, math channel, communication channel)
uuuuuuuuuu
Unit information (fixed to 10 characters. Unused character positions are
filled with spaces.)
pp
Decimal place (00 to 05)
The decimal place of the mantissa on channels set to LOG scale (/LG)
2.10 ASCII Output Format
