2-12
IM 04L51B01-17EN
2.3 Parameters
This section describes parameters.
2.3.1 Measuring Range Parameters
AI Channel Span
Specify the span using an integer.
Example If the range is -2.0000 V to 2.0000 V and you
want to set the span lower limit to 0.5000 V and the span
upper limit to 1.8000 V, set the parameters to 5000 and
18000, respectively.
SRangeAI,0001,VOLT,2V,FF,5000,18000,0
Scaling
Scaling is possible on AI and DI channels. Scaling is
specified by a mantissa and decimal place.
Example To set the scaling to -10.00 to 20.00, set the
scaling lower limit to -1000, scaling upper limit to 2000,
and the decimal place to 2. The decimal place value
represents the number of digits to the right of the decimal
point.
Math Channel and Communication Channel
Span
Set the span of math channels and communication
channels using a mantissa and decimal place.
Example To set the span to 1.000 to 2.000, set the
scaling lower limit to 1000, scaling upper limit to 2000,
and the decimal place to 3.
2.3.2 Parameter Notation and Range
The table below shows the principle parameter notations
and ranges of values.
Type Notation and Range of Values
[GX/GP]
Unit number
No expandable I/O 0
Expandable I/O installed 0 to 6
[GX/GP]
Module number
When the unit is GX10/GP10 0 to 2
When the unit is GX20/GP20 0 to 9
When the unit is an
expandable I/O
0 to 6
[GM]
Unit number
No sub unit 0
Sub unit installed 0 to 6
[GM]
Module number
Main unit 0 to 9
Sub unit 0 to 6
AI channel
DI channel
DO channel
PI channel
Specify as “unit number+module
number+channel.”
Example The AI channel whose unit
number is 0, module number is 1, and
channel number is 02 is 0102.
Type Notation and Range of Values
PID channel Specify as “unit number+slot
number+channel.”
Example The PID channel whose unit
number is 0, slot number is 1, and
channel number is 02 is 0102.
Note that the PID channel number
changes depending on the channel
type. The following table shows the
association.
Channel type Channel number (4 digits)
** is unit number+slot number
PV **01, **04
SP **02, **05
OUT **03, **06
AI **07, **08
AO **09, **10
DI **11 to **18
DO **19 to **26
Math channel GX20-2/GP20-2: 001 to 200
GX10/GP10: 001 to 050
GM10: 001 to 100
For SGroup and SMailAlarm
commands, insert “A” in front.
Example A001
If the measurement mode is dual
interval, the number of channels is
halved.
Communication
channel
GX10/GP10:001 to 050
GX20-1/GP20-1: 001 to 300
GX20-2/GP20-2: 001 to 500
GM10-1: 001 to 300
GM10-2: 001 to 500
For SGroup and SMailAlarm
commands, insert “C” in front.
Example C001
If the measurement mode is dual
interval, the number of channels is
halved.
Number of
channels for
recording
display data
GX10/GP10: 001 to 100
GX20-1/GP20-1: 001 to 500
GX20-2/GP20-2: 001 to 1000
GM10-1: 1 to 500
GM10-2: 1 to 1000
Number of
channels for
recording event
data
GX10/GP10: 001 to 100
GX20-1/GP20-1: 001 to 500
GX20-2/GP20-2: 001 to 1000
GM10-1: 1 to 500
GM10-2: 1 to 1000
Number of
channels for
recording
manual sampled
data
GX10/GP10/GX20-1/GP20-1: 1 to 50
GX20-2/GP20-2: 1 to 100
GM10-1: 1 to 50
GM10-2: 1 to 100
Number of
report channels
GX10/GP10: 1 to 50
GX20/GP20: 1 to 60
GM10: 1 to 60
Number of
display groups
GX10/GP10: 1 to 30
GX20-1/GP20-1: 1 to 50
GX20-2/GP20-2: 1 to 60
GM10-1: 1 to 50
GM10-2: 1 to 60
