2-100
IM 04L51B01-17EN
FPrgPtnCur (/PG)
Running Program Pattern Number and
Status Output
Outputs the running program pattern number and status
Syntax
FPrgPtnCur
Example
Output the running program pattern number
and status.
FPrgPtnCur
Description
•
This command is valid when the program control
function (/PG option) is in use.
•
When program operation is stopped, EA<crlf>EN<crlf>
is returned.
•
For the output format, see
page 2-169
.
2.5 Output Commands
117
119
Table of Contents
Default Chapter
3
Introduction
3
Recorder Version and Functions Described in this Manual
4
Conventions Used in this Manual
5
How to Use this Manual
5
Table of Contents
7
Chapter 1 Using Dedicated Commands (General)
9
Operations over an Ethernet Network
9
Preparing the Instrument
10
Sending Commands and Receiving Responses
10
Operations over the Serial Interface (RS-232, RS-422/485, USB, Bluetooth)
10
Connection Procedure (GX/GP)
11
RS-422/485 Connection Procedure
14
USB Connection Procedure (GM)
17
Bluetooth Connection Procedure (GM, /C8 Option)
18
Chapter 2 Commands and Responses
19
Command Transmission and Recorder Responses
19
General Communication
19
Command Types and Functions
19
Command Syntax
19
Recorder Responses
22
List of Commands
23
Setting Commands
23
Output Commands
26
Operation Commands
27
Communication Control Commands
27
Instrument Information Commands
28
Conditions for Executing Commands
28
How to Use Commands
29
Device Nomenclature in Command Descriptions
29
Parameters
30
Measuring Range Parameters
30
Parameter Notation and Range
30
Specifying a Range
31
Setting Commands
32
Recording Mode
35
Date Format
67
Display Settings
109
Output Commands
112
Operation Commands
119
Communication Control Commands
131
Instrument Information Output Commands
133
Responses to Commands
135
Affirmative Response (for Commands Other than Output Request Commands)
135
Negative Response
135
Data Output Response
136
Output in Response to RS-422/485 Commands
138
2.10 ASCII Output Format
139
Most Recent Channel Data (Fdata)
139
Most Recent (DO Channel) Status (Frelay)
140
Internal Switch Status (Frelay)
142
Latest Re-Transmission Output (AO Channel) State (Ftransstatao)
142
Users Who Are Currently Logged in (Fuser)
144
All Users Who Are Currently Logged in (Fuser)
146
Instrument Address (Faddr)
148
Recorder Status (Fstat)
149
Alarm Summary (Flog)
152
Message Summary (Flog)
153
Event Log (Flog)
154
Error Log (Flog)
154
Address Setting Log (Flog)
155
General Communication Log (Flog)
156
Modbus Communication Log (Flog)
157
FTP Client Log (Flog)
158
SNTP (Time Adjustment) Client Log (Flog)
159
E-Mail Client Log (Flog)
160
Web Log (Flog)
161
SLMP Log (Flog)
162
Control Alarm Summary (Flog)
163
Control Summary (Flog)
164
Detail Event Log Output (Feventlog) (/AS)
166
External Storage Medium and Internal Memory File List (Fmedia)
175
External Storage Medium Free Space (Fmedia)
175
Setting Data (Fcnf)
176
Decimal Place and Unit Information (Fchinfo)
176
System Configuration (Fsysconf)
177
Bluetooth Device Information (Fbtdevinfo)
179
Reminder Information Output (Freminder)
180
Outputs the most Recent Control Data (Fctrldata)
181
SP Number and PID Number Output (Fctrlno.)
182
Control Mode Output (Fctrlmode)
183
Program Operation Mode Output (Fprgmode)
184
Program Pattern Information Output (Fprgptninfo)
185
PV Event and Time Event Information Output (Fprgevent)
186
Program Control End Signal Status Output (Fprgend)
187
Currently Running Program Pattern Number and Status Output (Fprgptncur)
187
Instrument Manufacturer (_MFG)
188
Instrument's Product Name (_INF)
188
Instrument's Basic Specifications (_COD)
189
Instrument's Firmware Version Information (_VER)
189
Instrument's Option Installation Information (_OPT)
190
Instrument's Temperature Unit and Daylight Saving Time Installation Information (_TYP)
191
Instrument's Error Number Information (_ERR)
191
Instrument's Unit Configuration Information (_UNS or
192
Instrument's Module Configuration Information (_MDS or MDR)
193
2.11 Format of the Data Block of Binary Output
195
Most Recent Channel Data (Fdata)
195
Channel FIFO Data (Ffifocur)
198
FIFO Data Read Range (Ffifocur)
198
The most Recent Control Data (Fctrldata)
199
Appendix
203
Appendix 1 ASCII Character Codes
203
Appendix 2 Login Procedure
204
When Using the Login Function
204
When Not Using the Login Function
205
Appendix 3 Output Flow Chart of External Storage Medium Files and File Lists
206
Example for Outputting File Aaaa.dtd
206
Example for Outputting a File List
207
Appendix 4 FIFO Data Output Flow Chart
208
Overview of the FIFO Buffer
208
Example of FIFO Buffer Operation
208
Appendix 5 Check Sum Calculation Method
209
Appendix 6 Data Group Name and Data Name for WT Communication
210
Parameters P5 (Data Group Name) and P6 (Data Name) for Swattdata Command
210
Appendix 7 Bluetooth Communication Connection Flow Chart
216
