YOKOGAWA GX10 User Manual

2-182
IM 04L51B01-17EN
Data Time
Item (Number of Bits) Value
Year (8 bits) 0 to 99
Month (8 bits) 1 to 12
Day (8 bits) 1 to 31
Hour (8 bits) 0 to 23
Minute (8 bits) 0 to 59
Second (8 bits) 0 to 59
Millisecond (16 bits) 0 to 999
Additional Information (64 bits)
Bit 0: Daylight saving time (0: standard time; 1: daylight saving time)
Loop Number (16 bits)
001 to 692
Data Information (8 bits)
Indicates the data information (or the module status.)
0: Not used, 1: No data, 2: Normal, 3: Luck of data/Module not installed.
PVERR (8 bits)
Indicates the PV error.
Bit Value Description
0 to 4 0 No error
1 Skip
2 +OVER
3 -OVER
4 +Burnout
5 -Burnout
6 A/D error
7 Invalid data
5 0 No A/D calibration value error
1 A/D calibrattion value error
6 0 No RJC error
1 RJC error
7 0 Reserved
SPERR (8 bits)
Indicates the SP error.
Bit Value Description
0 to 4 0 No error
1 Skip
2 +OVER
3 -OVER
4 +Burnout
5 -Burnout
6 A/D error
7 Invalid data
5 0 No A/D calibration value error
1 A/D calibration value error
6 0 No RJC error
1 RJC error
7 0 Reserved
2.11 Format of the Data Block of Binary Output
