PVSEL (8 bits)
Indicates the status of PV input.
Bit Value Description
0 ON AI1 is used for PV1.
1 ON EXPV1 is used for PV1.
2 ON AI2 is used for PV2.
3 ON EXPV2 is used for PV2.
4 ON AI2 is used for PV1 (when PV switching is selected.)
5 ON EXPV2 is used for PV1 (when PV switching is selected.)
PV (32 bits)
Indicates the PV value using an integer.
When the data status is Over or Burnout, the integer will be the value of -5% to 105% of the
range.
SP (32 bits)
Indicates the SP value using an integer.
When the data status is Over or Burnout, the integer will be the value of -5% to 105% of the
range.
OUT (32 bits)
Indicates the OUT value using an integer.
However, when the Tight shut function is used, the SD is -S1 and Invalid data is -100.
2.11 Format of the Data Block of Binary Output
