YOKOGAWA GX10 User Manual

2-77
IM 04L51B01-17EN
Commands and Responses
1
2
App
p3 action p4 options
Conditions
in which
p3 is valid
when p4 is
not Off
Description Option
Off
DI1 to
DI8
DO1 to
DO8
ALM1_
L1 to
ALM4_
L1
ALO1_
L1 to
ALO4_
L1
ALM1_
L2 to
ALM4_
L2
ALO1_
L2 to
ALO4_
L2
Bit-2 of PID Number
LP2
PIDBit2_
LP2
x — x
Valid when
the PID
selection
is external
selection
(see even
loop settings)
Valid when
the control
mode is not
PV switching
Bit-3 of PID Number
LP2
PIDBit3_
LP2
x — x
Valid when
the PID
selection
is external
selection
(see even
loop settings)
Valid when
the control
mode is not
PV switching
SCtrlRelay
DO Terminal Action (Relay Action)
Sets the DO terminal action (relay action) of a PID
module.
When the output is “contact output within module”
Syntax
SCtrlRelay,p1,p2,p3,p4,p5,p6,p7
p1
Unit number
p2
Module number
p3
DO number (DO1 to DO8)
p4
Output type
CtrlRelay
Contact output within
module
p5
Loop selection
LP1
Loop 1
LP2
Loop 2
COMMON
Common to loop 1 and
loop 2
p6
Status (see the table below)
The valid range of p6 (status) varies
depending on the p5 (loop) options.
p7
Energize/De-energize (Energize, De_
Energize)
Energize
Energize
De_Energize
De-energize
p6 (status) Content p5 (loop)
OFF OFF LP1, LP2,
COMMON
ALM1_OUT_L1 Alarm 1 status loop 1 LP1
ALM2_OUT_L1 Alarm 2 status loop 1 LP1
ALM3_OUT_L1 Alarm 3 status loop 1 LP1
ALM4_OUT_L1 Alarm 4 status loop 1 LP1
ALM1_L1 Alarm 1 loop 1 LP1
ALM2_L1 Alarm 2 loop 1 LP1
ALM3_L1 Alarm 3 loop 1 LP1
ALM4_L1 Alarm 4 loop 1 LP1
SR_L1 STOP/RUN loop 1 LP1
AM_L1 AUTO/MAN loop 1 LP1
RL_L1 REMOTE/LOCAL loop 1 LP1
AT_L1 Auto-tuning status loop 1 LP1
EXPV_ANAPV_
L1
EXPV/LOCAL loop 1 LP1
ALM1_OUT_L2 Alarm 1 status loop 2 LP2
ALM2_OUT_L2 Alarm 2 status loop 2 LP2
ALM3_OUT_L2 Alarm 3 status loop 2 LP2
ALM4_OUT_L2 Alarm 4 status loop 2 LP2
ALM1_L2 Alarm 1 loop 2 LP2
ALM2_L2 Alarm 2 loop 2 LP2
ALM3_L2 Alarm 3 loop 2 LP2
ALM4_L2 Alarm 4 loop 2 LP2
SR_L2 STOP/RUN loop 2 LP2
AM_L2 AUTO/MAN loop 2 LP2
AUTO_L2 AUTO loop 2 LP2
MAN_L2 MAN loop 2 LP2
CAS_L2 Cascade loop 2 LP2
RL_L2 REMOTE/LOCAL loop 2 LP2
AT_L2 Auto-tuning status LP2
EXPV_ANAPV_
L2
EXPV/LOCAL loop 2 LP2
DI1 DI1 status output COMMON
DI2 DI2 status output COMMON
DI3 DI3 status output COMMON
DI4 DI4 status output COMMON
2.4 Setting Commands
