2-79
IM 04L51B01-17EN
Commands and Responses
1
2
App
p9
Bias (–999999 to 999999)
p10
Decimal Place (0 to 5)
p11
Scaling low limit
p12
Scaling high limit
p13
Unit (up to 6 characters, UTF-8)
p14
Low-cut function (Off, On)
p15
Low-cut point (0 to 50)
p16
Low-cut operation mode (Zero, Linear)
Query
SCtrlRangeAI[,p1.p2,p3]?
Example Measure -0.5000 to 1.0000 V on channel 0002.
No scaling. No bias.
SCtrlRangeAI,0002,Volt,2V,O
ff,–5000,10000,0
Description
This command is valid when a PID Control Module is
installed.
You cannot use this command to configure settings
while recording is in progress.
You cannot use this command to configure settings
while computation is in progress.
If p4=TC/RTD, p6 is set to Off.
If p4=TC/RTD/DI, p6 cannot be set to Sqrt.
If p4=Volt/GS/DI, p6 cannot be set to Off.
If p4=DI, you cannot set p9 (bias).
For electromagnetic relay type or low withstand
voltage relay type analog input modules, p2 cannot be
set to RTD.
The settable items for p5 are shown in the table
below.
p4=Volt p4=TC p4=RTD p4=GS p4=DI
20mV R Pt100 1-5V Level
60mV S Pt100-H 0.4-2V DI
200mV B JPt100
1V K JPt100-H
2V K-H Cu10GE
6V E Cu10LN
20V J Cu10WEED
50V T Cu10BAILEY
N Cu10a392
W Cu10a393
L Cu25
U Cu53
PLATINEL Cu100
PR20-40 J263B
WRe3-25 Ni100SAMA
KpvsAu7Fe Ni100DIN
NiNiMo Ni120
WWRe26 Pt25
N14 Pt50
XK Pt200WEED
Cu10G
Cu50G
Cu100G
Pt46G
Pt100G
For the setting ranges of p7 (span low limit) and p8
(span high limit), see the PID Control User’s Manual
(IM 04L51B01-31EN).
SCtrlBurnOut
Burnout Mode
Sets the burnout action of the AI terminal of a PID module.
Syntax
SCtrlBurnOut,p1,p2,p3,p4
p1
Unit number
p2
Module number
p3
AI terminal number (AI1, AI2)
p4 Burnout action (Off, Up, Down)
Query SCtrlBurnOut[,p1,p2,p3]?
Example When a burnout is detected on AI1 of module
number 2 connected to the main unit, set the
terminal to UP.
SBurnOut,0,2,AI1,Up
Description
This command is valid when a PID Control Module is
installed.
You cannot use this command to configure settings
while recording is in progress.
You cannot use this command to configure settings
while computation is in progress.
SCtrlRjc
RJC temperature
Sets the RJC temperature of the AI terminal of a PID
control module.
Syntax
SCtrlRjc,p1,p2,p3,p4,p5
p1
Unit number
p2
Module number
p3
AI terminal number (AI1, AI2)
p4
Mode (Internal, External)
Internal
Internal
External
External
p5
Compensation temperature
Fahrenheit -40 to 1760
Celsius -200 to 800
Absolute
temperature
2531~3532
Query SCtrlRjc[,p1,p2,p3]?
Example Set the reference junction compensation of
AI1 of module number 2 connected to the
main unit to internal compensation circuit.
SCtrlRjc,0,2,AI1,Internal
Set the reference junction compensation
of AI1 of module number 2 connected to
the main unit to external reference junction
compensation and the compensation
temperature to -2.3.
SCtrlRjc,0,2,AI1,External,-23
Description
This command is valid when a PID Control Module is
installed.
You cannot use this command to configure settings
while recording is in progress.
You cannot use this command to configure settings
while computation is in progress.
If p4=Internal, you cannot set p5.
Absolute temperature (K) is valid when the input type
is TC and the range type is KpvsAu7Fe.
